Wayfinding Event Directional Signage 220*220mm Wall Mounted / Hanging / Free Standing

Aurora Sign Event Directional Signage,Wayfinding Directional Signage

Aurora has a strong design team with 21 members, we have sufficient experiences in designing road signs and would like to share our experiences at our website. How to design a roadside sign is a big subject, which includes installation solutions.

Guidelines for Sign Installation

Normally, signs should be installed on separate posts except where a second sign is needed to supplement the primary sign or where route or directional signs must be grouped. Sign posts and their foundations should be able to hold signs rigidly in their proper and permanent position.

Rural Areas

In rural areas, signs are normally installed on a single 100 x 100 mm wooden post. In regions were strong winds are a problem, signs may be installed on a single 100 x 150 mm wooden post. For larger installations, post requirements must be determined based on the following criteria:

• Two posts are needed if the sign width exceeds 150 cm.
• Breakaway ground mounts are needed if the sign area exceeds three square metres (signs located outside the clear zone or protected by a guardrail do not need breakaway supporting structures).
• Signs greater than 5.5 m in width requires a three post mounting.

City Areas

In city areas, signs should preferably be installed on existing roadway appurtenances (such as street light and power poles) to
minimize the number of poles along the road.

Separate sign supports, if needed, should be installed as not to create a hazard to cyclists, motorcyclists, pedestrians and drivers. If used, rigid metal posts are more appropriate than wood posts because they can better withstand the impact when struck by an errant vehicle. They are also easier to replace, if needed.

In city areas the use of posts may be minimized by co‐mounting two or more signs on one post (where logical and practical). The criteria for mounting large ground mounted and overhead signs are the same as the criteria for mounting signs along rural highways.

Aurora is one of the top two sign manufacturers in China, we promise a 100% refund on our quality issues.

Aurora is your best signage supplier from China, please contact us if you want to buy signs from China.
