NB CatM GSM Global Vehicle Travel Trailer Gps Tracker For Valuables Position
MT17D GPS 2G network NB/catM GPS valuables position intelligent asleep hot salesn global GPS position
Adhering to the "customer-oriented" service concept, Kingwo will continue to focus on the location service sector, and continue to innovate around the needs of customers such as Internet+, auto finance, vehicle location services, asset location services, and person location services to provide the competitive products and service for the operators in the world and create maximum value for customers.
.
1. GPS asset tracker
2. Intelligent asleep
3. GPS Position and monitor
4. Multiple protocol
5. GPS valuables tracker
| Physical | Dimension | 110mm*40mm*45mm(L*W*H) |
| Weight | 120±5g | |
| Cellular | Module | Quectel EC25 |
| Frequency |
Working frequency: GSM/GPRS: 850/900/1800/1900MHz protocol: Embedded TCP/IP stack Sensitivity: -107dBm@850/900MHz -106dBm@1800/1900MHz Output power: Class 4 (2W)@850/900MHz Class 1 (1W)@1800/1900MHz GPRS data: GPRS Class 10, Mobile Station Class B |
|
| GPS |
Channels: 50 Sensitivity: -147dBm Position accuracy:5-10m Accuracy: 5m CEP Cold start: <27s Hot start: <1s |
|
| Processor | ST | |
| Motion sensor | DA260 | |
| Wifi position | Wifi 4.0 | |
| Power | Battery |
Disposable Lithium-ion battery and (3.6V,2800mAh) and ultra-low discharge rate:less than 1%, store one year below 25℃ |
| Power consumption | Average working current <100mA; Power save current <10uA; | |
| GSM antenna | Internal High Gain | |
| GPS antenna | Internal High Gain | |
| SIM | MicroSIM | |
| Indicator | 2 status LEDs, Green: GPS, Red: Celluar | |
| Environmental Parameter | Working Temperature | -20℃ ~ +70℃ |
| Humidity | 5% ~ 95% (no fog) | |
| Ingress Protection Rating | IP67 | |
