9-100V Cat1 4G Wired Vehicle GPS Trackers Device Support Relay For Trucks
Cat-1 Asia version 4G wired gps tracker for cars motorcycle trucks support relay
LT01 -1A is a Cat-1 Asia version 4G wired gps tracker for cars motorcycle trucks support relay,multiple functions support remote engine off,anti-theft,real time tracking and driving behavior.This version is focus on Asia and other countries which support those network bands.
Network frequency :
LTE FDD: Band 1/3/5/8
LTE TDD: Band 34/38/39/40/41
Function
- Real-time tracking monitoring, Real-time GPS tracking, History playback, Blind data storage, Cornering compensation
- Track according to time, distance and speed
- LBS and AGPS Positioning
- Low voltage and main power cut off alarm
- Towing alarm
- Remote power and fuel cut off (Relay required)
- Mileage calculation
Parameters:
| Physical | Dimension | 88mm*45mm*14mm(L*W*H) |
| Weight | 47±5g | |
| Cellular | Lte module | Fibcom L610 |
| Frequency |
Working frequency: •LTE FDD: Band 1/3/5/8 •LTE TDD: Band 34/38/39/40/41 • GSM: 900/1800MHz • LCC 31x28x2.4mm • Operating Temperature: -40℃~+85℃ • Operating Voltage: 3.3V~4.3V typical 3.8V |
|
| GPS |
Channels: 50 Sensitivity: -147dBm Position accuracy:5-10m Accuracy: 5m CEP Cold start: <27s Hot start: <1s |
|
| Power | Input voltage | 9-100V |
| Battery | NI-MH AAA 3.6V/110mA, 2 hours working time based on 2-3 minutes upload | |
| Power consumption |
Average Current: <30mA (DC 12V) Maximum current: <10mA (DC 12V) |
|
| Interface | Digital input(1) | Ignition detect |
| Digital output(1) | Relay | |
| GSM antenna | Internal High Gain | |
| GPS antenna | Internal High Gain | |
| SIM | Microsim | |
| Indicator | 2 status LEDs, Green: GPS, Red: 4G | |
| Memory | 1300 pcs | |
| Environmental Parameter | Working Temperature | -20℃ ~ +70℃ |
| Humidity | 5% ~ 95% (no fog) | |
| Ingress Protection Rating | IP65 | |
Alarm function
1. Low Voltage Alarm
When the battery voltage on the vehicle is too low (0-11V or 19-22V), device will report a low voltage alarm to the backend
2. Speeding, low speed alarm
When the vehicle speed is higher than the preset alarm value, the device will notify the backend. Similarly, when the vehicle speed is lower than preset alarm value, a low speed alarm will be uploaded to the backend, this value is configurable.
3. Vibration alarm
The device supports vibration alarm, 10 minutes after the ignition off (Arm range 1-20 minutes), the device generates vibration (Delay range 1-10 mins) without ACC connected, the device will upload vibration alarm.
4. Towing alarm
An alarm will be generated when the device is set to a displacement of more than 100 meters (message mode prompt), and the alarm information will be reported when the displacement radius exceeds 100 meters when the device is turned off. (Note: displacement range 100~2000m)
The device will send SMS if the vehicle is moved in ignition off status, if the radius is more than 100 meters, will upload towing alarm (Towing range:100-2000m)
