real time gps tracker for motorcycle gps tracker anti thefting GSM wired devices
real time gps tracker for motorcycle gps tracker anti thefting GSM wired devices
MT200 is real time motorcycle gps tracker 2g multiple hidden gps tracker for motorcycle,cars,ebikes and escooters.This one is a hardwired tracker with BLE for tracking powered assets and vehicles, with ignition detection and output for relay/buzzer/siren.
Low Voltage Alarm
When the battery voltage on the vehicle is too low (0-11V or 19-22V), device will report a low voltage alarm to the backend
Over speed alarm
When the vehicle speed is higher than the preset alarm value, the device will notify the backend. Similarly, when the vehicle speed is lower than preset alarm value, a low speed alarm will be uploaded to the backend, this value is configurable.
Driving behavior alarm
The device is built in with G-sensor, which can detect speeding, hard deceleration, hard acceleration and Cornering alarm
Turn over alarm
If someone turn over the device, it will report an alarm.
Vibration alarm
The device supports vibration alarm, 10 minutes after the ignition off (Arm range 1-20 minutes), the device generates vibration (Delay range 1-10 mins) without ACC connected, the device will upload vibration alarm.
Towing alarm
An alarm is generated when the device is set to a displacement of more than 100 meters (message mode prompt), and the alarm information is reported when the displacement radius exceeds 100 meters when the device is turned off. (Note: displacement range 100~2000m).
The device will send SMS if the vehicle is moved in ignition off status, if the radius is more than 100 meters, will upload towing alarm (Towing range:100-2000m).
Wire cut off alarm
The device is allowed to connect a power off relay for power and fuel cut off function in case a car stolen happens, a command can be sent to the device to remote cut off the fuel and power, please note only the preconfigured center number can send such command.
GPS error alarm
When the device detects that the GPS module is working abnormally, it reports the GPS receiver failure alarm to the backend.
Device removal alarm
Device is with built in light sensor, when it detects the lights vary, it will report removal alarm to the backend
Specifications:
| Physical | Dimension | 75*40*13mm |
| Weight | 45±3g | |
| Cellular | GSM module | Quectel MC25 |
| Frequency |
Working Frequency: 850/900/1800/1900MHz Network protocol: Embedded TCP/IP stack |
|
| GPS |
Channels: 50 Sensitivity: -147dBm Position accuracy:5-10m Accuracy: 5m CEP |
|
| Bluetooth | Bluetooth 5.0 | |
| Power | Input voltage | 9-100V |
| Battery | NI-MH AAA 3.6V/60mA | |
| Power consumption |
Average Current: <30mA Maximum current: <10mA |
|
| Interface | Digital input(2) | Ignition detect and Air condition status detect |
| Digital output(1) | Relay | |
| Analog input 1 | Voltage range:0-36V | |
| GSM antenna | Antenna inside | |
| GPS antenna | Antenna inside | |
| SIM | Microsim | |
| Indicator | Green: GPS, Red: GSM | |
| Environmental Parameter | Working Temperature | -20℃ ~ +70℃ |
| Humidity | 5% ~ 95% (no fog) | |
| Ingress Protection Rating | IP65 | |
Software
Kingwo also provide software package along with MT200 models and many others from our company, see below details:
Web-based software: www.itracksense.com
Users:vdftest
Password:test
Smart phone Application: Track Sense
FAQ:
Q: Are you a manufacturer?
A: Yes, we work hard on the development and production of high-precision tracking for more than 5 years. We have worked with
other manufacturers as well,so customers can do one stop buy from us.
Q: Is sim card included for the gps tracker?
A: No, sim card not included,customers have to buy sim card from local store.
Q: How do I track the location of the gps device?
A: You could track it by PC platform or application by IOS or Android Phone. We offer lifetime free APP and platform for users.
