GHDCU10 VET Full Digital Color Doppler GYN Vet Diagnostic Ultrasound

Name: GHDCU10 VET Full Digital Color Doppler GYN Vet Diagnostic Ultrasound
Brand: Hefei DX Medical Co., Ltd.

Price Negotiable

Price: 1

MOQ: 2

Delivery Time: 7

Brand: GH

Product Description

GHDCU10 VET full digital color Doppler ultrasound diagnostic instrument veterinary ultrasound

Overview

Quick Details

Place of Origin:: China

Brand Name:: GH

Model Number:: GHDCU10VET

Power Source:: Electric

Warranty:: 1 Year

After-sale Service:: Online technical support

Material:: Metal, Plastic

Shelf Life:: 1years

Quality Certification:: ce

Instrument classification:: Class I

Safety standard:: None

Product name:: Veterinary Ultrasound Machine

Type:: Doppler Ultrasound Equipment

Application:: Vet

Keyword:: veterinary ultrasound

Function:: Animals diagnostic

Feature:: portable

Display:: 15" LCD

Imaging mode:: B/M/Color/PDI/PW

Item:: Vet Ultrasound

Weight:: 10kg

Supply Ability

Supply Ability: 500 Piece/Pieces per Month

Packaging & Delivery

Packaging Details: In general we use the Standard Export Cartons.
Also we can packing the products based on customers' demand.

Port: Tianjin or Qingdao

GHDCU10VET full digital color Doppler ultrasound diagnostic instrument

Instructions for use  Application range of instrument: DCU10 have the leading image process technical and practical clinic solution method, apply to ultrasound diagnosis of Bovine, Equine, Camel, Canine, Feline, Goat, Ovine and Swine. For examine of abdomen, heart, gynecology, obstetrics, urology, small organs, blood vessels, etc.

Specifications:
Size:	400(L)394(H)172(W)
Weight:	only unit 7.5kg, with one probe 8.2kg, with two probes 8.9kg.
Channel:	64 channels
Monitor:	High resolution 15 "LCD display
Imaging mode	1.B mode 2. M mode 3. Color (Color Doppler ) mode 4. PDI (Energy Doppler)mode 5. PW (Pulse Doppler)mode
Image display mode	B,2B,B+M,4B,M,B+Color,B+PDI,B+PW,B+Color+PW,B+PDI+PW,★B+C/PDI Double real time
Supported probes	1. Convex probe 2. Linear probe 3. Cavity probe 4. Micro-convex probe
Probe frequency:	2.5-10.0MHz
Probe socket:	2 PC
Image storage:	1. Support JPG, BMP, FRM image formats and CIN,AVI movie format 2. Support local storage; 3. ★Support DICOM, meet the DICOM3.0 standard; 4. ★Built-in workstations: Support large-capacity hard disk (≥500GB),support patient data retrieval and browsing.
System language:	1. Chinese / English operating system and language environment, support other languages according to user requirement; 2. Full screen annotation input, Chinese/ English; Chinese input methods ≥2,including Wubi input method
Battery	Built-in high-capacity lithium battery, continue to work more than 1.5 hours, power information displayed on the screen.
