300x300mm Optical Breadboard Vibration Isolation Plate For Experiment
Vibration Isolation Plate For Optical Experiment , Bread Honeycomb Board PT-02PB
SPECIFICATION:
1.height: 13mm
2.finish: matte black anodized ,Matte Black Anodized Finish Reduces Unwanted Reflections
3.hole size and spacing: M6 Tapped Holes on 25 mm Centers
5.High quality aluminum alloy material.
6.Portable and easy to install.
7.The breadboard is rock solid anti-deformation.
|
Model |
Size(mm) |
Thickness (mm)(C) |
Mounting Hole Type (mm) |
Aperture |
Surface Flatness (mm) |
Weight(kg) |
|
PT-02PB300x300 |
300x300 |
13 |
25x25 |
M6 |
0.1 |
3 |
|
PT-02PB300x450 |
300x450 |
13 |
25x25 |
M6 |
0.1 |
5 |
|
PT-02PB300x600 |
300x600 |
13 |
25x25 |
M6 |
0.15 |
6 |
|
PT-02PB300x900 |
300x900 |
13 |
25x25 |
M6 |
0.2 |
9 |
|
PT-02PB300x1200 |
300x1200 |
13 |
25x25 |
M6 |
0.3 |
12 |
|
PT-02PB600x600 |
600x600 |
13 |
25x25 |
M6 |
0.15 |
12 |
|
PT-02PB600x900 |
600x900 |
13 |
25x25 |
M6 |
0.2 |
18 |
|
PT-02PB600x1200 |
600x1200 |
13 |
25x25 |
M6 |
0.3 |
25 |
|
PT-02PB900x900 |
900x900 |
13 |
25x25 |
M6 |
0.2 |
28 |
|
PT-02PB900x1200 |
900x1200 |
13 |
25x25 |
M6 |
0.3 |
37 |
|
PT02PB1200x1200 |
1200x1200 |
13 |
25x25 |
M6 |
0.3 |
50 |
Note:
Because of the different size of the optical plate.Then the weight is different.And,The freight will be big different.
So,Please only place order to me ,Don't pay it, I need to change the freight before your payment.
Thanks.
Optical Breadboard Handle(A Couple):
|
Product Name |
Optical Breadboard Square Handle |
|
Criterion |
International Standard |
|
Material |
Aluminum Alloy |
|
Surface Preparation |
Spray-Paint |
|
Center Hole Distance |
90mm |
