Manual Worm GearSwing Platform With Locking , Goniometer Stage PT-SD302

The manual angle table is one of the adjustment frame instruments in the adjustment frame. It can reach the specified position through rotating the guide rail to realize the application of positioning and coupling. According to different application fields, the selected accuracy and stroke are also different.

Precision manual angle table: PT-SD302

Characteristic:

■ provide small rotation angle adjustment.

■ adopt fine grinding V-shaped guide rail + ball guide rail.

■ worm gear pair drive, comfortable movement, precision and reliability.

■ the operation of the table is stable and the deflection and inclination are small.

■ paired design, the rotation center is the same point after superposition, and the orthogonal biaxial concentric rotation adjustment can be carried out.

■ hand wheel locking, safe and reliable.

■ the table is placed horizontally and has standard connecting holes, which can form a multi-dimensional adjustment frame with other series of products.

Product parameters:

Product Dimension Map:
