80mm Outlet High Lift Pump Diesel Water Pump 90m Max Head For Fire Protection
Price:
Negotiable
MOQ:
100 units mixed model
Delivery Time:
25 work days
Brand:
RAMS
Product Description
MOQ:20units mixed model
3 inch High lift cast iron pump Diesel engine
Features
• High lift and large flow
• Mountain irrigation, sprinkler irrigation, etc
• The operation is simple
• 1-cylinder,4-stroke,air-cooled
APPLICATION SCOPE:
• Agricultural production
• Mining and metallurgical industries
• Life water supply
• Waterlogging and drought resistance
• Landscaping
• The fire application
• Mining and metallurgical industries
• Life water supply
• Waterlogging and drought resistance
• Landscaping
• The fire application
| Power | Diesel engine | |
| Name | High lift cast iron pump | |
| Model | 3X3-188 | 3X3-208 |
| Inlet(mm) | 80 | 80 |
| Outle(mm) | 80 | 80 |
| Max flow[m³/h] | 40 | 44 |
| Max head(m) | 75 | 90 |
| Suction(m) | 7 | |
| Speed[rpm] | 3600 | |
| Engine model | 186F | 188F |
| Engine type | 1-cylinder,4-stroke,air-cooled | |
| Displacemen(ml) | 418 | 456 |
| Ratedpower[KW(Hp)] | 7.5(10) | 8.0(11) |
| Starting system | Recoil starter/Electric starter | |
| Continuous working time[h] | 8 | |
| Fuel tank capacity(L) | 5.5 | |
| lube oil capacity(L) | 1.65 | |
| Overall dimension[mm] | 630X530X590 | |
| Package size(mm) | 640X540X605 | |
| Net weight(kg) | 100 | |
| Gross weight(kg) | 102 | |
