China 4 Stroke Air Cooled Diesel Welding Generators 300A With 25L Diesel Tank for sale

4 Stroke Air Cooled Diesel Welding Generators 300A With 25L Diesel Tank

Price Negotiable

Price: Negotiable

MOQ: 100 units mixed model

Delivery Time: 25 work days

Brand: RAMS

Product Description

Genset 300 Amp Diesel Welder 4 stroke Air cooled With 25L Diesel Tank

MOQ:2units mixed model

• with voltage fluctuation automatic compensation, thrust automatic compensation ability, stable welding

current, excellent dynamic characteristics, fast response speed, small splash, strong penetration.

• Welding current is continuously and accurately adjustable.
• Output AC 8 kW power supply, suitable for all kinds of acid and alkaline electrode: more than 30% energy

saving than the traditional welding machine.
• Suitable for: electric power, municipal, chemical, tap water, gas pipeline construction, etc.

Model No.		AXC1-300AF
genset	Excitation mode	AVR
	The prime power	8KW
	The standby power	8.5KW
	Rated voltage	400V
	Rated ampere	Each phase 17.8A
	Max ampere	Each phase 18.8A
	frequency	50HZ
	phase	3 phase 380V 50Hz
	Power factor (COSφ)	0.8
	Insulation grade	F
Engine	engine	2V92
	Bore × stroke	92x75mm
	displacement	997cc
	Fuel consumption	≤320g/kw.h
	Ignition system	Compression ignition
	Engine type	Inline,twin cylinder ,4 stroke, air cooled, direct injection
	Fuel	diesel:0#(summer)-10#(winter)-35#(severely cold)
	Oil capacity	2.6L
	startup	Electric
others	Fuel capacity	25L
	battery	12V-45AH free maintenance battery
	noise	87dBA/7m
	size	1100x750x950mm
	Net weight	232kg
	Rated input power	12.2KVA
	Rated input ampere	18.6A
	Welding A/V	315A/32.6V
	Welding A	315A60%DE
	Welding A	200A100%DE
	No load voltage	67±5V
	Ampere set range	20-350A
	efficiency	≥85%
welder	Power factor	>0.95
	Insulation grade	F
	Cooling system	Air cooled
	Protection grade	IP21S
