Waterproof Solar Rechargeable LFP Li Ion Battery 3.4KWH For Backup Protection
Price:
$1,498.00/units >=50 units
MOQ:
50 units
Delivery Time:
Negotiable
Brand:
Coslight
Product Description
Product Specification
Brief Introduction :
CPW series is an integrated battery system for backup protection when the grid goes down.And it can be charged by either electricity from your utility or solar power. CPW has four working modes: SOL(Solar First), UEI(Utility First),SBU(Solar-Battery-Utility),SUB(Solar-Utility -Battery). These working modes are described refer to the setting part of user manual.
|
Models
|
CPW3400
|
|
|
|
Battery
|
Nominal Voltage
|
51.2V
|
|
|
|
Voltage Range
|
45~57.6V
|
|
|
|
Capacity
|
3.4KWH
|
|
|
|
Max.discharge Rate
|
1C
|
|
|
|
Max.charge Rate
|
1C
|
|
|
|
Battery Type
|
Li-ion(LFP)
|
|
|
AC Output
|
Rated Power
|
3000W
|
|
|
|
Surge Power
|
6000W
|
|
|
|
Output Voltage
|
220/230/240Vac
|
|
|
|
Output Current
|
13.7A
|
|
|
|
Rated Frequency
|
50/60Hz
|
|
|
|
VTHD
|
＜3%
|
|
|
|
Output Wave
|
Pure Sine Wave
|
|
|
|
Output Type
|
Euro Round Socket×2+Terminals
|
|
|
|
Max. Efficiency
|
93%
|
|
|
AC Input
|
AC Input Voltage Range
|
170-280VAC
|
|
|
|
AC Input Frequency
|
50/60Hz
|
|
|
|
Max AC Charge Current(Battery)
|
30A(0~60A Adjustable)
|
|
|
PV Input
|
Max. PV Power(Recommended)
|
1500W
|
|
|
|
Max. PV Voltage
|
145V
|
|
|
|
MPPT Range
|
60V~115V
|
|
|
|
Max PV Charge Current(Battery)
|
30A
|
|
|
Operating Conditions
|
Operating Temperature
|
0~55℃
|
|
|
|
Storage Temperature
|
-15℃~60℃
|
|
|
|
Humidity
|
5%~95%
|
|
|
|
Cooling Strategy
|
Fan
|
|
|
|
Product Weight
|
48kg
|
|
|
|
Dimension [W x H x D]
|
TBD
|
|
|
|
Packing
|
wooden case
|
|
|
|
Packing Dimension [W x H x D]
|
TBD
|
|
|
|
Enclosure Protection Rating
|
IP20
|
|
|
|
Communication
|
WIFI/RS485
|
|
