PC simplex Fiber Optics Cables Multi Mode With MTP/MPO Connector
Description
MTP/MPO harness cables are a kind of breakout/fanout MPO cable assembly with one MTP/MPO connector on one end and multiple single-fiber connectors (LC, SC, FC, etc.) on the other end, designed for data distribution and routing to patch panels. It is used to transitioning from trunk backbone assemblies to fiber rack system. The harness cables are fully configurable, available with a variety of cable and connector combinations. For the hardware and equipment in the same cabinet, the longer patch cords can provide flexibility at any location, and the branch cables can be winded into the vertical cable organizer.
| Product Name: | Fiber Optic Patch Cord | Model Name: | MTP/MPO Harness Cable |
|---|---|---|---|
| Fiber Mode: | OM3 Multi Mode | Fiber Length: | 10M |
| Connector: | MPO-LC | Working Environment: | -20°C to +70°C |
| Fiber Type: | simplex | Polish: | PC |
Product Description
Features
- Low loss performance
- MPO / MTP in 8/12/16/24/32 fibers interface for choices.
- Available in OS1, OS2, G.657A2, OM3, OM4 Fiber Grades – OM1 and OM2 available upon request
- Option for LSZH, OFNP or OFNR cablejacket
- 100% factory terminated and tested
- Pulling eyes are provided as an option to protect the fiber ends during installation
- Save installation and reconfiguration time
Applications
- Data Center Interconnect
- High-Density Fiber Management
- Telecommunication Networks and CATV networks
- LAN/WAN Premises
Standards
- TIA/EIA-568.3-D and ISO/IEC 1180
- IEC-61754 & EIA/TIA-604-5
- NFPA 262 or IEC 60332 EN 50575
- Comply with GR-1435-CORE, GR-2866-CORE, GR-326-CORE
- Compliant to Directive 2002/95/EC (RoHS) and REACH SvHC
Quality control
