12F Optical Fiber Pigtail ,12 core Fiber Cable Patch Cord 1m sc lc
12F optical fiber cable patch cord 12 core fiber pigtails 1m sc lc
Optical patch Cord and pigtail is the basic parts for optical transmission. They are consist of fiber optic cable and terminated connector. Wolon has strong capacity and experience to support any large demand.
Features
- Low Insertion Loss, High Return Loss
- Good Repeatability and Interchangeability
Applications
- Long-haul, Metro and Access System
- Fiber CATV and Fiber Network System
Specifications:
| Parameter | Unit | Value | |||
| Connector Type | FC/UPC,FC/APC,SC/UPC,SC/APC,LC/UPC,LC/APC,ST/PC,MPO | ||||
| Fiber Type | Multi-Mode | Single Mode | |||
| Insertion Loss | dB | Typ.≤0.1 Max.≤0.2 |
Typ.≤0.1 Max.≤0.3 |
||
| Return Loss (Typ.) | dB | ≥36 (no APC connector) | /PC | /UPC | /APC |
| ≥45 | ≥50 | ≥55 | |||
| Repeatability | dB | ≤0.1 | |||
| Interchangeability | dB | ≤0.2 | |||
| Connection Durability | times | ≥1000 | |||
| Operating/Storage Temperature | °C | -40~+80 | |||
More Question
1. Can I have a sample order?What is your MOQ?
Yes, we welcome sample order to test and check quality. We do not have MOQ,1 sample is available.
2. What is the lead time?
For usual products,We keep stock,could ship about 3 days after received payment.For big quantity and special products,Please check lead time with our sales representative.
3. How do you ship the goods and how long does it take arrive?
We usually ship by DHL, UPS, FedEx or TNT. It usually takes 3-5 days to arrive.
4. What is your payment terms?
Usually,we need prepayment by T/T,West Union or Paypal.
Could also support L/C,Credit terms.
5. What is your warranty time
We promise 3 years warranty for all products shipped from us.
6. Could I return the products if there is a quality problem?
Yes,if there is a quality problem happen,we could accept free exchange.
7. Could i use our own logo and label?
Yes,we could provide a OEM service and make the products with your own label.
