IEC 61076-3-106 Waterproof Fiber Optic Connector Multimode Single Mode
Waterproof Connector
Product Description
Features
- Cost effective solution for in house termination
- Water proof, dust proof and corrosion resistant
- Wide range of operational temperature
- Wide range of cables to be used,3-8mm OD cable with two 2.0mm to 3.0mm jacketed subunits
- Multimode and single mode
- Intermateable to other Industrial adaptor per IEC 61076-3-106
- Simple assembly requiring no special tools
- Durable mechanical mating,minimum of 500 mating
Applications
- Outdoor environment of optical fiber communication
- Outdoor communication equipment connection
- Optical fiber base station connection
- Field optical communication link temporary fast connection
- Broadband
- CATV
- FTTP
Specifications
| Parameter | FullAXS-LC | Optitap-SC | MINI-SC | ODVA-SC | ODVA-LC | ODVA-MPO |
ODVA-MPO (Low loss) |
PDLC | ||||||||
| SM | MM | SM | MM | SM | MM | SM | MM | SM | MM | SM | MM | SM | MM | SM | MM | |
| Insertion Loss(dB) | 0.2 | 0.2 | 0.2 | 0.2 | 0.2 | 0.2 | 0.2 | 0.2 | 0.2 | 0.2 | 0.75 | 0.5 | 0.35 | 0.35 | 0.2 | 0.2 |
| Return Loss(dB) | 50 | / | 50 | / | 50 | / | 50 | / | 50 | / | 60 | 25 | 60 | 25 | 50 | / |
|
Cable outer Diameter(mm) |
4.8 or 7.0 | 3 or 5 | 3 or 5 | 3 ~ 8 | 3 ~ 8 | 3 ~ 8 | 3 ~ 8 | 3 ~ 7 | ||||||||
| IP Rating | IP67 | IP67 | IP67 | IP68 | IP68 | IP68 | IP68 | IP67 | ||||||||
| Durability | <0.2dB typical change 500 matings | |||||||||||||||
|
Operating Temperature |
-40°C to +70°C | |||||||||||||||
More Question
1. Can I have a sample order?What is your MOQ?
Yes, we welcome sample order to test and check quality. We do not have MOQ,1 sample is available.
2. What is the lead time?
For usual products,We keep stock,could ship about 3 days after received payment.For big quantity and special products,Please check lead time with our sales representative.
3. How do you ship the goods and how long does it take arrive?
We usually ship by DHL, UPS, FedEx or TNT. It usually takes 3-5 days to arrive.
4. What is your payment terms?
Usually,we need prepayment by T/T,West Union or Paypal.
Could also support L/C,Credit terms.
5. What is your warranty time
We promise 3 years warranty for all products shipped from us.
6. Could I return the products if there is a quality problem?
Yes,if there is a quality problem happen,we could accept free exchange.
7. Could i use our own logo and label?
Yes,we could provide a OEM service and make the products with your own label.
