Efficient Heating And Cooling Heat Pump WIFI R32 Environment Friendly Refrigerant
R32 New environment-friendly refrigerant Efficient Heating And Cooling Heat Pump
Why do we use R32?-- Eco-friendly R32
R32 is a new environmentally friendly refrigerant with higher pressure and faster cooling speed than r410, which makes the product highly efficient and environmentally friendly. At the same time, R32 refrigerant has thermal properties, environmental protection characteristics, safety and circulation performance.
Why do we use full DC inverter Panasionc compression?-- Efficient
Dc converters design circuits that allow transformers or inductors to operate at higher frequencies, so the components are smaller, lighter and more affordable, which greatly improves the efficiency of the SUNRAIN R32.
| Model: | BLN-010TB1 | ||
| Power Supply | V/Ph/Hz | 220~240/1/50 | |
| Nominal Heating (Max) (A7/6℃, W30/35℃) | Heating Capacity | kW | 10.58 (4.20-12.20) |
| Power Input | kW | 2.29 | |
| COP | W/W | 4.62 | |
| Nominal Heating (Max) (A7/6℃, W47/55℃) | Heating Capacity | kW | 9.47 |
| Power Input | kW | 3.09 | |
| COP | W/W | 3.06 | |
| Nominal Cooling (Max) (A35/24℃, W12/7℃) | Cooling Capacity | kW | 8.34 |
| Power Input | kW | 2.66 | |
| EER | W/W | 3.14 | |
| ERP Level(Outlet water temp. at 35℃) | / | A+++ | |
| ERP Level(Outlet water temp. at 55℃) | / | A++ | |
| Rated input power | kW | 3.83 | |
| Rated input current | A | 17.00 | |
| Refrigerant / Weight | / | R32 | |
| Rated water flow | m3/h | 1.75 | |
| Fan quantity | / | 1 | |
| Fan motor type | / | DC inverter | |
| Compressor | / | Panasonic / DC inverter / Rotary / EVI | |
| Circulating pump | / | Inverter type / Built-in | |
| IP Class | / | IPX4 | |
| Sound pressure at 1m distance | dB(A) | 51 | |
| Max outlet water temperature | °C | 60 | |
| Water piping connections | / | DN 25 (1") | |
| Pressure drop at rating water flow | kPa | 27 | |
| Operating temperature range (Heating mode) | °C | -30~45 | |
| Operating temperature range (Cooing mode) | °C | 16~45 | |
| Unpacked Dimensions ( L×D×H ) | mm | 1100×445×850 | |
| Packed Dimensions ( L×D×H ) | mm | 1150×580×1000 | |
| UnPacked Weight | kg | 107 | |
| Packed Weight | kg | 119 | |
