R32 Inverter Air To Water Swimming Pool Air Source Heat Pump 17KW
R32 Inverter Air To Water Swimming Pool Heat Pump 17 KW Pool Heater
| Product Features | |
| *Model | BYC-017TV1 |
| *Air Flow Direction | Horizontal |
| *Rated Heating Capacity Air 26℃ ( Water 26℃ in, /28℃ out ) |
16.5~3.8kw |
| *Rated Heating Capacity Air 15℃ ( Water 26℃ in, /28℃ out ) |
13.1~3kw |
| *Rated Cooling Capacity Air 35℃ ( Water 29℃ in, /27℃ out ) |
9.4~2.1kw |
| *Refrigerant | R32 |
| *Working temp. range | -15℃~43℃ |
A heat pump is a part of a home heating and cooling system and an energy-efficient alternative to a furnace. A heat pump uses electricity to transfer heat from a cool space to a warm one. In the winter, it takes the heat from outdoors and uses it to heat your home. And during the summer, it moves the heat from inside your home to outside to cool your home.
Energy-efficient: ASHPs deliver one to three times more energy than the electricity they consume.
ASHP can help lower your fuel bills, especially if you are replacing older, inefficient heating and cooling systems.
Versatile (all year long): ASHPs can heat your home in the winter and cool your home in the summer.
Easy: ASHP is easy to install and require little maintenance
Product Parameters
| Model No. | BYC-007TV1 | BYC-010TV1 | BYC-013TV1 | BYC-017TV1 |
| * General data | ||||
| Power supply | 220~240V/1/50 | |||
| Max Power Input (kW) | 1.45 | 1.75 | 2.2 | 2.5 |
| Max Current (A) | 7.1 | 8.3 | 10.2 | 11.9 |
| Water Flow Volume (m3/h) | 2.5 | 3.5 | 4.5 | 5.5 |
| Refrigerant | R32 | |||
| Heat Exchanger | Titanium | |||
| Air Flow Direction | vertical | |||
| Working temp. range (℃) | -15~43 | |||
| Casing Material | ABS | |||
| Water Proof Level | IPX4 | |||
| Noise level 1m dB(A) | 41~51 | 42~54 | 44~55 | 45~57 |
| Noise level 10m dB(A) | 21~31 | 22~34 | 24~35 | 25~37 |
| Net Weight (kg) | 44 | 46 | 55 | 57 |
| Gross Weight (kg) | 55 | 57 | 68 | 70 |
| Net Dimensions (mm) | 530*530*640 | 650*650*770 | ||
| Package Dimensions (mm) | 560*600*780 | 680*720*910 | ||
