-30℃ Inverter EVI Heat Pump System Energy Class A++ 12 Kw Heat Pump
-30℃ Inverter EVI Heat Pump System 12KW Energy Class A++
| Model | BLN-012TA1 |
| Power supply V/Ph/Hz | 220-240/1/50 |
| Installation | Freestanding |
| Factory | Guangdong China |
When going green is important, the SUNRAIN air source is a great choice. Conventional forced-air systems have provided comfort for decades, but despite the increased efficiency, they do contribute to global warming and ozone layer depletion. SUNRAIN air source can greatly reduce your carbon footprint.
The maximum outlet water temperature of the equipment can reach55°C, which means that the machine can meet a large amount of water demand.
SUNRAIN's industrial heat pump water heater is suitable for various applications. Its innovative design not only beautifies the area but also increases its safety. It is designed in such a way that the electricity is carefully separated from the water flow, thus making it 100% vibration-proof. However, one of the nicest things about this water heater is that it allows you to set the time and temperature of the hot water using its smart digital controller. Thus, it is very user-friendly.
Product Parameters
| Model | BLN-012TA1 | ||
| Power supply | V/Ph/Hz | 220-240/1/50 | |
| Performance Condition: Outdoor air 7℃ / 6℃, Inlet / Outlet water 30℃ / 35℃ | |||
| Heating | Capacity (min-max) | kW | 4.6 ~ 12.8 |
| Rated input(min-max) | kW | 0.8 ~ 3.9 | |
| SCOP | 4.31 | ||
| Performance Condition: Outdoor air 7℃ / 6℃, Inlet / Outlet water 50℃ / 55℃ | |||
| Heating | Capacity | kW | 4.7 ~ 12.9 |
| Rated input | kW | 1.4 ~ 5.1 | |
| SCOP | 3.30 | ||
| Performance Condition: Outdoor air 35℃ / 24℃, Inlet / Outlet water 12℃ / 7℃ | |||
| Cooling | Capacity | kW | 2.6 ~ 9.1 |
| Rated input | kW | 1.9 ~ 6.1 | |
| EER | 2.77 | ||
| Energy class (SCOP) | Outlet water temp. at 35C | A++ | |
| Outlet water temp. at 55C | A++ | ||
| Max input current | A | 24.0 | |
| Max input power | KW | 5.5 | |
| Compressor | Type - Quantity/System | Twin Rotary - 1 | |
| Refrigerant | Type | R32 | |
| Charged volume | kg | 1.8 | |
| Fan | Quantity | 1 | |
| Airflow | m3/h | 3000 | |
| Rated power | W | 100 | |
| Noise level | Heating | dB(A) | 45 |
| Cooling | dB(A) | 46 | |
| Water flow volume | m3/h | 1.5 | |
| Water piping connections | mm | DN25 Male | |
| Operating temperature range | Cooling | C | -5 - 48 |
| Heating | C | -30 - 48 | |
| DHW | C | -30 - 48 | |
| Outlet water temperature range | Cooling | C | 5 - 25 |
| Heating | C | 25 - 55 | |
| DHW | C | 40 - 55 | |
| Net dimensions (WxDxH) | mm | 1005×375×800 | |
| Packed dimensions (WxDxH) | mm | 1080x455x830 | |
| Net/Gross weight | kg | 75/85 | |
Sample Project
We are based in Guangdong, China, start from 2012,sell to Domestic Market(85.00%),Western Europe(3.00%),Southeast Asia(3.00%),Southern Europe(3.00%),Northern Europe(2.00%),Africa(2.00%),North America(1.00%),South America(1.00%). There are total about 501-1000 people in our office.
2. how can we guarantee the quality?
Always a pre-production sample before mass production;
Always final Inspection before shipment;
3. what can you buy from us?
heat pump water heater, air-source heat pump, swimming pool heat pump, inverter heat pump, EVI heat pump
4. why should you buy from us, not from other suppliers?
Sunrain is a listed company with the biggest and most advanced heat pump production factories all over China. We have a very strong and professional R&D team with more than 50 employees. Sunrain spent over 6 million RMB to build the most advanced labs.
5. what services can we provide?
Accepted Delivery Terms: FOB,CFR,CIF,EXW,DDP,DDU；
Accepted Payment Currency:USD,EUR,JPY,CAD,AUD,HKD,GBP,CNY,CHF;
Accepted Payment Type: T/T,L/C,D/P D/A,MoneyGram,Credit Card,Western Union,Cash,Escrow;
Language Spoken:English,Chinese,Spanish,Portuguese,German,French
