Auto Restart Minisplit Inverter 19 Seer Cool Pump 12000 btu ac 60Hz
Auto Restart Minisplit Inverter 19 Seer Cool Pump 12000 btu ac 60Hz
Introduction of basic product information
a. Wireless LCD Remote Control.
b. Auto Fan Settings.
c. Auto Restart.
d. Timer.
e. Sleep Mode.
product features
Rotary Compressor. Superquiet Operation. 19.0 Seer in Cooling Mode. High Efficiency Cooling & Heating. Durable cabinet with protective coating.
Gold Fin( Optional ) :
It can improve the heating efficiency by accelerating the defrosting process,and also
be resistant to the salty air, rain, and other corrosive elements.
|
|
||
|
OUTDOOR UNIT
|
||
|
OUTDOOR UNIT MODEL NO.
|
37HL012J24(3C) | |
|
Outdoor fan motor speed (Hi/Mi/Lo) (r/min)
|
800/750/650 | |
|
Design pressure (PSIG)
|
550/340 | |
|
Qty’per 20’ /40’ /40'HQ
|
84/178/214 | |
| Refrigerant piping |
Liquid side/ Gas side (mm/inch)
|
6.35mm(1/4in)/12.7mm(1/2in) |
|
Max. refrigerant pipe length (m)
|
25 | |
|
Max. refrigerant pipe length (ft)
|
82.02 | |
|
Max. difference in level (m)
|
10 | |
|
Max. difference in level (ft)
|
32.81 | |
|
Connection wiring
|
16AWG*4 Stranded, unshielded | |
|
Thermostat type
|
Remote Control | |
|
Outdoor noise level (dB(A))
|
55 | |
|
Room temperature outdoor(cooling/heating) (℃)
|
-15~43/-25~30 | |
|
Room temperature outdoor(cooling/heating) (℉)
|
5~109.4/-13~86 | |
|
Refrigerant type (oz)
|
R410A/0.84 | |
| Dimension |
WxDxH (mm)
|
800x333x554 |
|
WxDxH (inch)
|
31.50x13.11x21.81 | |
|
Packing (WxDxH)(mm)
|
920x390x615 | |
|
Net/Gross weight (Kg)
|
30.4/33 | |
