110V 60Hz Fixed Speed Air Conditioner Cooling Only R410A air conditioner
Price:
negotiate
MOQ:
50 sets
Delivery Time:
20-25days
Brand:
DELTA
Product Description
110V 60Hz R410A Cooling Only Fixed Speed Air Conditioner
Customized different logo air conditioner mini split
| Model No. | VAC-09CSA/* | VAC-12CSA/* | VAC-18CSA/* | VAC-24CSA/* | ||
| Type | cooling only | cooling only | cooling only | cooling only | ||
| Control type | remote | remote | remote | remote | ||
| Rated cooling capacity | Btu/h | 9000 | 12000 | 18000 | 24000 | |
| Moisture removal | Liters/h | 1 | 1.5 | 2.0 | 2.4 | |
| Indoor noise level at cooling | High | dB(A) | 36 | 39 | 42 | 48 |
| Med. | dB(A) | 34 | 36 | 39 | 46 | |
| Low | dB(A) | 32 | 34 | 36 | 44 | |
| Outdoor noise level | dB(A) | 52 | 55 | 58 | 60 | |
| Power supply | 220~240V~/50Hz | |||||
| Voltage Range | V | 198~264 | 198~264 | 198~264 | 198~264 | |
| Rated current | Cooling | A | 4.2 | 5.5 | 8.5 | 11.2 |
| Rated input | Cooling | W | 930 | 1220 | 1870 | 2470 |
| Annual energy consumption | kwh (cooling) | 465 | 610 | 935 | 1235 | |
| Max Current | Cooling | A | 5.5 | 7.2 | 11.1 | 14.6 |
| Max Power input | Cooling | W | 1200 | 1590 | 2430 | 3210 |
| Refrigerant/Charge | Gram | R410A | R410A | R410A | R410A | |
| Compressor | Type | Rotary | Rotary | Rotary | Rotary | |
| Brand | RECHI | RECHI | RECHI | HIGHLY | ||
| Indoor air circulation(Cooling) | m3/h | 480 | 520 | 780 | 780 | |
| Indoor fan type | Cross flow | Cross flow | Cross flow | Cross flow | ||
| Outdoor fan type | Propeller | Propeller | Propeller | Propeller | ||
| Connecting Pipe | Gas | mm | Φ9.52(3/8'') | Φ12(1/2'') | Φ12(1/2'') | Φ15.88(5/8'') |
| Liquid | mm | Φ6(1/4'') | Φ6(1/4'') | Φ6(1/4'') | Φ9.52(3/8'') | |
| Connecting Wiring | Size x Core number | 1.0x3 | 1.0x3 | 1.5x3 | 4×0.75 | |
| Suitable area | m2 | 9~16 | 15~23 | 20~35 | 30~50 | |
| Net dimensions (W x H x D) | Indoor | mm | 718×240×180 | 770×240×180 | 900×280×202 | 900×280×202 |
| Outdoor | mm | 600×232×500 | 700×256×552 | 760×256×552 | 902×307×650 | |
| Packing dimensions (W x H x D) | Indoor | mm | 805×305×255 | 855×305×255 | 985×365×298 | 985×365×298 |
| Outdoor | mm | 745×353×550 | 803×361×600 | 863×361×590 | 1028×430×705 | |
| Net weight | Indoor | kg | 6 | 7 | 10 | 10 |
| Outdoor | kg | 24 | 29 | 35 | 51 | |
| Gross weight | Indoor | kg | 8 | 10 | 13 | 13 |
| Outdoor | kg | 27 | 33 | 39 | 57 | |
| Loading Capacity | 20'/40'/40'HC | 132/277/310 | 103/235/275 | 95/198/222 | 61/132/156 | |
DELTA HVAC is a Global Green Field (GGF) Heating and Cooling Manufacturing Company with a penchant for unique, efficient and ECO friendly products. Our global deliverables are geared towards improving our customer's comfort yet adding detailed engineering through extensive market research and quality compliance. Our Standards are determined through continual product improvement and manufacturing techniques uniquely designed with the environment in mind.
FAQ
Q: How about the packing?
A: packed in carton, can customized different logo according to customers' requirements.
Q: What about the warranty?
A: We can give 0.5% free spare parts of the total value when order confirmed. If large quantity of products run abnormally from certain shipment, our engineer will join the inspection or return faulty goods to the factory for further tests when necessary. Once it proves to be our quality problems, we will provide replaced models in next shipment for free.
Q: How about your quality control system for Air Conditioner production?
A: There is a quality certified process for our external materials suppliers before we purchase materials from them. The metal parts will produce by our workshop under our strict QC control. Before on line production, all the materials will be inspected by the IQC, only the past will send to the assemble line. And then in line we step with IPQC, IQC, who will make sure each unit in good quality. Before shipment, the QA will make inspection for the goods and only the past lot can inform the customers for his inspection or shipment arrangement.
Q: If I have a question, how can I get contact with your side?
A: You can leave us message or inquiry then we will contact you. Or you can directly call us or send us direct mail or fax to consult us.
A: packed in carton, can customized different logo according to customers' requirements.
Q: What about the warranty?
A: We can give 0.5% free spare parts of the total value when order confirmed. If large quantity of products run abnormally from certain shipment, our engineer will join the inspection or return faulty goods to the factory for further tests when necessary. Once it proves to be our quality problems, we will provide replaced models in next shipment for free.
Q: How about your quality control system for Air Conditioner production?
A: There is a quality certified process for our external materials suppliers before we purchase materials from them. The metal parts will produce by our workshop under our strict QC control. Before on line production, all the materials will be inspected by the IQC, only the past will send to the assemble line. And then in line we step with IPQC, IQC, who will make sure each unit in good quality. Before shipment, the QA will make inspection for the goods and only the past lot can inform the customers for his inspection or shipment arrangement.
Q: If I have a question, how can I get contact with your side?
A: You can leave us message or inquiry then we will contact you. Or you can directly call us or send us direct mail or fax to consult us.
