Residential Split System Air Conditioner Fixed Speed Efficiency Portable 240V
Home Appliances Fixed Speed Air Condtioner improve cooling efficiency portable
As we expand on our Global Product Offering, our focus would always be on the environment. Delta's manufacturing partners are indeed the most qualified and trusted keepers within our Industry, leading the stand on CO2 reduction vertically.
As we continue to build comfortable spaces efficiently and affordably, our Global Certifications are consistently updated and maintained making Delta HVAC a unique Brand of Choice to our customers.
Reverse Cycle Fixed Speed Models Specifications
| Model | 7K | 9k | 12k | 18k | 24k | 30k | ||
| GSC-07HA | GSC-09HA | GSC-12HA/A | GSC-18HA | GSC-24HA | GSC-30HA | |||
| Type | heating pump | heating pump | heating pump | heating pump | heating pump | heating pump | ||
| Control type | remote | remote | remote | remote | remote | remote | ||
| Rated cooling capacity | Btu/h;W | 7000;2050 | 9000;2640 | 12000;3520 | 18000;5280 | 24000;7030 | 30000;8800 | |
| Rated heating capacity | Btu/h;W | 7500;2200 | 9500;2800 | 12500;3700 | 18500;5420 | 24500;7200 | 30500;8940 | |
| EER for cooling | W/W | 10.98;3.22 | 10.98;3.22 | 10.95;3.21 | 11.02;3.23 | 10.98;3.22 | 10.65;3.12 | |
| Class in Cooling | A | A | A | A | A | A | ||
| COP for heating | W/W | 3.61 | 3.61 | 3.62 | 3.61 | 3.63 | 3.53 | |
| Class in Heating | A | A | A | A | A | A | ||
| Moisture removal | Liters/h | 0.8 | 1 | 1.2 | 2 | 2.2 | 2.4 | |
| Pressure | High(DP) | MPa | 4.5 | 4.5 | 4.5 | 4.5 | 4.5 | 4.5 |
| Low(SP) | MPa | 1.9 | 1.9 | 1.9 | 1.9 | 1.9 | 1.9 | |
| Indoor noise level(S/H/M/L/Mute) | dB(A) | 35/33/29/27/25 | 35/33/29/27/25 | 43/40/37/33/31 | 43/40/38/37/37 | 43/43/38/37/37 | 51/46/41/37/37 | |
| Outdoor noise level | dB(A) | 50 | 50 | 52 | 55 | 55 | 62 | |
| Electrical Data | ||||||||
| Power supply | 220-240V~/50Hz/1P | 220-240V~/50Hz/1P | 220-240V~/50Hz/1P | 220-240V~/50Hz/1P | 220-240V~/50Hz/1P | 220-240V~/50Hz/1P | ||
| Voltage Range | V | 198~264 | 198~264 | 198~264 | 198~264 | 198~264 | 198~264 | |
| Rated current | Cooling | A | 2.95 | 3.8 | 5.1 | 7.6 | 10.1 | 13.1 |
| Heating | A | 2.83 | 3.6 | 4.7 | 7 | 9.2 | 11.7 | |
| Rated input | Cooling | W | 640 | 820 | 1100 | 1640 | 2180 | 2820 |
| Heating | W | 610 | 775 | 1020 | 1500 | 1985 | 2530 | |
| Annual energy consumption(cooling) | kwh | 350 | 410 | 550 | 820 | 1090 | 1360 | |
| Max Current | Cooling | A | 4.6 | 4.9 | 6.6 | 9.9 | 13.1 | 16.7 |
| Heating | A | 4.6 | 4.9 | 6.6 | 9.1 | 12 | 15.3 | |
| Max Power input | Cooling | W | 1000 | 1060 | 1430 | 2130 | 2830 | 3660 |
| Heating | W | 1000 | 1060 | 1430 | 2130 | 2580 | 3300 | |
