Small Size Multi Split Air Conditioner AMS 220V Multi Split Ac System 50Hz
Multi Split Air Conditioner Factory
Product features:
1. Small size, small footprint, convenient arrangement.Compact size, good balance and quick installation.Symmetrical structure, bright lines, crisp edges, beautiful appearance.
2. Italian AMS production line is adopted to produce high heat transfer efficiency of turbulent fin steel tube heat exchanger, with high efficiency.
3. Fan has three kinds of speed adjustable, and the use of permanent capacitor motor, so that the fan is the most energy-saving, good effect.
4. High precision bearing motor without lubricating oil and special sound-absorbing insulation material are adopted for smooth operation, low noise and long service life.
Parameters
| Model and Performance | FP-34 | FP-51 | FP-68 | FP-85 | FP-102 | FP-136 | FP-170 | FP-204 | FP-238 | ||
| Rated air volume m3/h | High | 340 | 510 | 680 | 850 | 1020 | 1360 | 1700 | 2040 | 2380 | |
| Medium | 260 | 390 | 510 | 640 | 770 | 1020 | 1280 | 1530 | 1790 | ||
| Low | 170 | 260 | 340 | 430 | 510 | 680 | 850 | 1020 | 1190 | ||
| Reted cooling capacity KW | H | 1.98 | 2.8 | 3.87 | 4.58 | 5.42 | 7.38 | 9.08 | 11.1 | 12.9 | |
| H | 1702 | 2408 | 3328 | 3938 | 4661 | 6346 | 7808 | 9546 | 11094 | ||
| Rated heating capacity KW | H | 3.39 | 4.5 | 6.35 | 7.45 | 9.22 | 12.4 | 16.3 | 19.5 | 20.2 | |
| H | 2915 | 3870 | 5460 | 6407 | 7930 | 10665 | 14020 | 16770 | 17370 | ||
| Input power W | 12Pa | H | 37 | 52 | 62 | 76 | 96 | 134 | 152 | 189 | 228 |
| 30Pa | H | 44 | 59 | 72 | 87 | 108 | 156 | 174 | 212 | 253 | |
| 50Pa | H | 49 | 66 | 84 | 100 | 118 | 174 | 210 | 250 | 300 | |
| Noise dB(A) | 12Pa | H | 37 | 39 | 41 | 43 | 45 | 46 | 48 | 50 | 52 |
| 30Pa | H | 40 | 42 | 44 | 46 | 47 | 48 | 50 | 52 | 54 | |
| 50Pa | H | 42 | 44 | 46 | 47 | 49 | 50 | 52 | 54 | 56 | |
| Water flow rate Kg/h | 350 | 510 | 660 | 800 | 980 | 1280 | 1600 | 1920 | 2230 | ||
| Water resistance Kpa | 30 | 30 | 30 | 30 | 40 | 40 | 40 | 40 | 50 | ||
| Power supply | 220V/50Hz | ||||||||||
Packing & Delivery
in export standard carton
