Residential Multi Split Air Conditioner DC Wall Mounted Double Crank
Residential Multi Split Air Conditioners DC Central Air Conditioner Commercial Air Conditioner
Main Features
1) Simple structure in linear type ,easy in installation and maintation.
2) Adopting advanced world famous brand components in pneumatic parts ,electric parts and operation parts.
3) High pressure double crank to control the die opening and closing.
4) Running in a high automatization and intellectualization,no pollution
5) Apply a linker to connect with the air conveyor ,which can directly inline with filling machine .Main Features
1) Simple structure in linear type ,easy in installation and maintation.
2) Adopting advanced world famous brand components in pneumatic parts ,electric parts and operation parts.
3) High pressure double crank to control the die opening and closing.
4) Running in a high automatization and intellectualization,no pollution
5) Apply a linker to connect with the air conveyor ,which can directly inline with filling machine .
Specification
|
Model
|
—
|
GMV-80WL/C-T
|
GMV-100WL/C-T
|
GMV-121WL/C-T
|
|
|
Capacity range
|
HP
|
3
|
3.5
|
4
|
|
|
|
Cooling
|
KW
|
8
|
10
|
12.1
|
|
Heating
|
KW
|
9
|
11
|
13
|
|
|
EER
|
W/W
|
3.90
|
3.70
|
3.51
|
|
|
COP
|
W/W
|
4.74
|
4.40
|
4.81
|
|
|
Power supply
|
|
V/Ph/Hz
|
220-240/1/50 &280-230/1/60
|
||
|
Max. Circuit / Fuse Current
|
A
|
25
|
25
|
32
|
|
|
Power comsumption
|
Cooling
|
kW
|
2.05
|
2.7
|
3.45
|
|
Heating
|
kW
|
1.9
|
2.5
|
2.7
|
|
|
Maximum drive IDU NO.
|
unit
|
4
|
5
|
6
|
|
|
Refrigerant Charge volume
|
kg
|
1.8
|
1.8
|
2
|
|
|
Sound pressure level
|
dB(A)
|
56
|
56
|
57
|
|
|
|
Liquid
|
mm
|
Φ9.52
|
||
|
Gas
|
mm
|
Φ15.9
|
Φ15.9
|
||
|
|
Outline
|
mm
|
980×360×790
|
||
|
Package
|
mm
|
1097×477×937
|
|||
|
Net weight/Gross weight
|
kg
|
80/90
|
80/90
|
85/95
|
|
|
|
40'GP
|
set
|
96
|
96
|
96
|
|
40'HQ
|
set
|
96
|
96
|
96
|
|
centrifugal fan blade and low-noise volute are
adopted. Meanwhile, the imported silent valve isadopted to reduce noise of entire unit as low as 22dB(A).
By adopting the optimal inlet angle of centrifugal fan blade and optimal diameter ratio between internal and external circles of impeller, the air volume is increased and fan noise is decreased greatly.
The advanced supercooling control technology and the oil-return technology under heating mode has efficiently solved the problem of liquid flow noise of indoor unit , which improved the sound quality of indoor unit.
