Low Noise ABS Panel Commercial Cool Ac Cassette Light Commercial Air Conditioner
Price:
Negotiate
MOQ:
50 sets
Delivery Time:
15-20dys
Brand:
DELTA
Product Description
Low Noise Ceiling Mounted Air Conditioner/Air conditioning Cassette Type
Product Description
1. ABS panel .
2. Centrifugal blower .
3. Motor ,Class E , three speeds , motor surface spray painting, good corrosion resistance,fully sealed, permanently sealed and lubricated ball bearings .
4. Coil ,the copper tube is mechanically expanded to ensure close contact with the aluminum fins, high heat transfer efficiency. Strong corrosion resistance. All coils are qualified by 2.4 Mpa pressure leak detection.
5. Configured with drain pump.
3. Motor ,Class E , three speeds , motor surface spray painting, good corrosion resistance,fully sealed, permanently sealed and lubricated ball bearings .
4. Coil ,the copper tube is mechanically expanded to ensure close contact with the aluminum fins, high heat transfer efficiency. Strong corrosion resistance. All coils are qualified by 2.4 Mpa pressure leak detection.
5. Configured with drain pump.
Remark:
1. Cooling testing condition return air dry ball/wet ball temperature 27℃/19.5℃ ,chilled water inlet temperature 7℃ , chilled water outlet temperature 12 ℃.
2. Heating testing condition return air dry ball temperature 21 ℃ ,hot water inlet temperature 60℃, hot water outlet temperature 50 ℃.
|
Product Parameters
|
|||||||||
|
Model
|
FP-51
|
FP-68
|
FP-85
|
FP-102
|
FP-136
|
FP-170
|
FP-204
|
FP-238
|
|
|
Air current indoorm³/h
|
High
|
510
|
680
|
850
|
1020
|
1360
|
1700
|
2040
|
2380
|
|
Middle
|
420
|
580
|
700
|
740
|
1150
|
1400
|
1650
|
2000
|
|
|
Low
|
210
|
420
|
520
|
620
|
840
|
1050
|
1250
|
1480
|
|
|
Cooling Capacity(W)
|
|
3000
|
3800
|
4900
|
5800
|
7000
|
9800
|
11000
|
1200
|
|
Heat(W)
|
4700
|
5900
|
7600
|
9000
|
10900
|
15200
|
17100
|
18600
|
|
|
Wind turbines form
|
|
||||||||
|
Noise(db)
|
36/33/31
|
39/38/34
|
45/43/41
|
45/43/41
|
47/42/36
|
50/47/42
|
50/4742
|
50/47/43
|
|
|
Alternator type
|
|
||||||||
|
Number of motors
|
1
|
1
|
1
|
1
|
1
|
1
|
1
|
1
|
|
|
Power
|
220V-50HZ
|
||||||||
|
W Power Consumption
|
30
|
45
|
70
|
90
|
128
|
154
|
180
|
200
|
|
|
coil pipe
|
Model
|
|
|||||||
|
working pressure
|
|
||||||||
|
Joint pipe
|
|
|
|||||||
|
Water resistance(kPa)
|
20
|
20
|
20
|
20
|
24
|
30
|
35
|
40
|
|
|
Drain size
|
φ26
|
||||||||
|
Panel external diameter
|
650*650*30
|
950*950*66
|
|||||||
|
Unit dimensions
|
585*585*250
|
840*840*225
|
840*840*290
|
||||||
|
Unit weight
|
23
|
23
|
24
|
27
|
27
|
30
|
30
|
30
|
|
|
Noted: FP-51,FP-68 The air conditioner blows on all sides, FP-85,FP-102,FP-136,FP-170,FP-204,FP-238 Air comes out on eight sides of the air conditioner
|
|||||||||
|
Due to the product improvement, the above parameters may be changed, the name brand parameters of the product shall prevail
|
|||||||||
