480V Metal Roof Ridge Cap Machine PLC Ridge Making Machine 0.3mm-0.8mm PPGI
Color Steel 480V PLC Ridge Cap Forming Machine For 0.3mm - 0.8mm PPGI
1. description of Ridge Cap Forming Machine
Color Steel roof ridge cap forming machine is used to produce metal roof ridge tile which is one type popular metal construction material,this material is usually used with other metal roof sheets,they are widely used in the construction of various industrial plants, villages, warehouses, supermarkets, hotels, exhibition, family construction, shopping malls shutter doors and etc.It has the advantage of beautiful, classical appearance and grace taste.
2. Specifications of Ridge Cap Forming Machine
| No. | main parameter of ridge tile roll forming machine | |
| 1 | Suitable to process | Color steel sheet |
| 2 | Width of the plate | 320mm |
| 3 | Roller steps | 14 rows |
| 4 | Dimensions | 6.8m*0.9m*1.51m (depend on different profile) |
| 5 | Power | 3+3kw(according customer's requirement) |
| 6 | Thickness of the plate | 0.3-0.8mm |
| 7 | Productivity | 1-3m/min |
| 8 | Diameter of the shaft | Φ60mm |
| 9 | Weight | About 5.5T |
| 10 | Voltage | 380V 50Hz 3 phases |
| 11 | Material of the cutting plate | Cr12 |
| 12 | Hydraulic | 40# |
| 13 | Processing precision | Within 1.00mm |
| 14 | Control system | PLC control |
| 15 | Diameter of roller | 70mm |
| 16 | Hydraulic oil | 40# |
3. Advantage of Ridge Cap Forming Machine
- durable
- withstand servere conditions.
- low cost
- low initial investment and low maintain cost
- environment friendly
- all the material can be recycled
- flexible design
- can relocate
- install time considerably reduced
- Operate easily , work automatically with PLC controller control.
4. details photos of Ridge Cap Forming Machine
