Dc01 Dc06 Galvanized Steel Coils
Price:
Elaborate
MOQ:
1 ton
Delivery Time:
5-25days
Brand:
TISCO
Product Description
Hot Rolled Dc01 Dc02 Dc03 Dc06 Galvanized Steel Coils
Galvanized steel coil can be divided into general use, roof use, building outer side plate use, structural use,tensile use and deep drawing use.
The galvanizing production line is a complete set of equipment for hot-dip galvanizing a layer of zinc alloy coating on both sides of steel coils. The production line is composed of uncoiler, welding machine, storage machine, degreasing cleaning unit, continuous annealing furnace, zinc pot, air knife, finishing machine, tension straightener, oiler, shear, coiler and other equipment.
|
Technical Standard
|
EN10147, EN10142, DIN 17162, JIS G3302, ASTM A653
|
|
Steel Grade
|
Dx51D, Dx52D, Dx53D, DX54D, S220GD, S250GD, S280GD, S350GD, S350GD, S550GD; SGCC, SGHC, SGCH, SGH340, SGH400, SGH440,
SGH490,SGH540, SGCD1, SGCD2, SGCD3, SGC340, SGC340 , SGC490, SGC570; SQ CR22 (230), SQ CR22 (255), SQ CR40 (275), SQ CR50 (340), SQ CR80(550), CQ, FS, DDS, EDDS, SQ CR33 (230), SQ CR37 (255), SQCR40 (275), SQ CR50 (340), SQ CR80 (550); or Customer’s Requirement |
|
Type
|
Coil/Strip
|
|
Thickness
|
0.12-6.00mm,or customer's requirement
|
|
Width
|
600mm-1500mm, according to customer's requirement
|
|
Type of Coating
|
Hot Dipped Galvanized Steel(HDGI)
|
|
Zinc Coating
|
30-275g/m2
|
|
Surface Treatment
|
Passivation(C), Oiling(O), Lacquer sealing(L), Phosphating(P), Untreated(U)
|
|
Quality
|
Approved by SGS,ISO
|
|
Coil Weight
|
3-10 metric ton per coil
|
|
Package
|
Water proof paper is inner packing,galvanized steel or coated steel sheet is outer packing , side guard plate,then wrapped by
seven steel belt.or according to customer's requirement |
|
Export market
|
Europe, Africa, Central Asia, Southeast Asia, Middle East, South America, North America, etc
|
|
Delivery Time
|
Usually within 10-45 days after receipt of advance payment
|
