2025 Best Price LPG Gas Storage tank ASME 10ton
2025 Best Price LPG Gas Storage tank ASME 10ton
Description
An LPG tank, also known as an LPG container, industrial gas tank, compressed gas tank, or liquefied gas tank, is a special device designed to store liquefied petroleum gas (LPG). LPG is a hydrocarbon gas mixture commonly used as fuel in industrial, agricultural, and commercial sectors. To facilitate transportation and storage, LPG is typically liquefied at high pressure and stored in LPG tanks.
LPG tank parameter
|
Capacity (m3) |
600 |
1500 |
2000 |
3000 |
5000 |
6000 |
8000 |
|
Filling Ratio |
0.9 |
0.85 |
0.9 |
0.9 |
0.9 |
0.9 |
0.9 |
|
Tank Net Weight (KG) |
84395 |
258610 |
288617 |
431223 |
636868 |
732400 |
893620 |
|
Design Pressure (MPa) |
1 |
1.77 |
1.77 |
1.77 |
1.8 |
1.77 |
1.42 |
|
Working Pressure (MPa) |
0.8 |
1.57 |
1.4 |
1.57 |
1.7 |
1.57 |
1.2 |
|
Design Temperature (ºC) |
-52/35 |
-20/50 |
-20/50 |
-20/50 |
-40/50 |
50 |
-30/50 |
|
Working Temperature (ºC) |
|
-18/40 |
35 |
-15/40 |
-35/40 |
40 |
-15/40 |
|
Corrosion Allowance (mm) |
2.0 |
1.0 |
1.5 |
1.5 |
1.5 |
1.0 |
2.0 |
|
Seismic Intensity |
6 degree |
7 degree |
7 degree |
7 degree |
8 degree |
8 degree |
8 degree |
Working with LPG tanks
The following safety measures are recommended when working with LPG tanks:
- It’s advisable to install a LPG bulk tank in a well-ventilated or outdoor area and at ground level. Mechanical ventilation systems should be considered in order to guarantee the provision of fresh air.
- LPG tanks must be protected against any source of ignition or heat and incorporate a fire-resistance rating. Combustible materials should also be put away from LPG tanks, as well as anything that may potentially generate static electricity.
- These installations should be located far away from incompatible substances and barrier systems should be considered (for instance, a screen wall made from non-combustible materials).
- Alarm systems and air-quality testing are recommended in order to monitor potential LPG leakages.
- Staff must wear adequate PPE when manipulating LPG tanks in order to avoid freezer burns and other hazards.
- Correct maintenance programs must be guaranteed to avoid tank bursts and other safety issues.
- Pressure-relief valves are common accessories for a LP gas cylinder. These can help release pressure in case a pressure build-up endangers the system.
- The engineering team in charge of designing and implementing LPG tanks must follow the required national and international legislation and quality protocols.
- LPG tanks must be stored in a vertical position and their valves closed. The use of appropriate restraining methods must also be considered, including chains or safety straps.
- These storage solutions must also keep all necessary documentation registering the safety measures that have been undertaken, as well as all documentation related to dangerous goods protocols.
If you require other types of gas storage tanks, please visit our products and services page or email us at info@gneeheatex.com.
