10-15Kap VPSA Oxygen Plant 10-5000 Nm3/Hr For Medical Use
Price:
Negotiable
MOQ:
≥1sets
Delivery Time:
Transit time: Est. 17-24 days
Brand:
GNEE
Product Description
93%-99.5% Customized Advanced VPSA Oxygen Plant for Medical
The VPSA Oxygen Generator utilizes pressure swing adsorption technology with zeolite molecular sieve as the adsorbent. The molecular sieve selectively adsorbs nitrogen while allowing oxygen to concentrate in the gas phase, achieving efficient nitrogen-oxygen separation. The system employs a dual-adsorption-tower configuration where one tower produces oxygen while the other regenerates under negative pressure. PLC-controlled pneumatic valves alternate the towers continuously to ensure stable, high-quality oxygen output.
Product Parameters
Main technical parameters of VPSA oxygen production: Purity 93%
| Model specification | HL-200 | HL-300 | HL-400 | HL-500 | HL-600 | HL-800 | HL-1000 |
|---|---|---|---|---|---|---|---|
| Gas production Nm³/h | 200 | 300 | 400 | 500 | 600 | 800 | 1000 |
| Voltage | 380v | 380v | 380v | 380v | 380v | 10kv | 10kv |
| Installed power KW | 120 | 165 | 200 | 270 | 317 | 380 | 450 |
| Valve gas consumption m³/min | 0.5 | 0.7 | 0.9 | 1.1 | 1.4 | 1.6 | 2.0 |
| Cooling water circulation m³/h | 11 | 15 | 20 | 26 | 30 | 38 | 55 |
| Soft water consumption m³/h | 1.2 | 1.8 | 1.98 | 2.1 | 2.1 | 2.4 | 2.7 |
Main technical parameters of VPSA oxygen production: Purity 95%
| Model specification | HL-1200 | HL-1600 | HL-2000 | HL-3000 | HL-3600 | HL-4500 | HL-5500 |
|---|---|---|---|---|---|---|---|
| Gas production Nm³/h | 1200 | 1600 | 2000 | 3000 | 3600 | 4500 | 5500 |
| Voltage | 10kv | 10kv | 10kv | 10kv | 10kv | 10kv | 10kv |
| Installed power KW | 565 | 715 | 1000 | 1250 | 1600 | 2000 | 2500 |
| Valve gas consumption m³/min | 2.0 | 2.4 | 3.0 | 3.3 | 4.2 | 5.5 | 6.5 |
| Cooling water circulation m³/h | 62 | 90 | 100 | 110 | 120 | 130 | 140 |
| Soft water consumption m³/h | 2.7 | 2.88 | 3.3 | 3.6 | 4.2 | 4.5 | 4.8 |
Technical Characteristics
- Purification equipment uses carbon-supported catalyst requiring no hydrogen source, ensuring safe and easy operation
- Dual-tower switching capability allows for dehydration desiccant replacement or maintenance without system shutdown
- Premium carbon-supported catalyst extends replacement cycles while maintaining oxygen purity above 99.9995%
- PLC-controlled automatic tower switching eliminates potential human error in manual operations
We also manufacture PSA Oxygen Generators, storage tanks, heat exchangers and related products. For inquiries about VPSA Oxygen Systems or other equipment, please contact us at info@gneeheatex.com. Our team is ready to assist with your oxygen generation needs.
