Industrial PSA Oxygen Generator with 0.1-0.8MPa Pressure and ≥90%±3% Oxygen Purity for Laser Cutting
Price:
According to the product
MOQ:
≥1sets
Delivery Time:
Negotiable
Brand:
GNEE
Product Description
Industrial PSA O2 Oxygen Generator Machine System Plant For Laser Cutting
Product Advantages
- Simple installation and maintenance thanks to modular design and construction
- Fully automated system for simple and reliable operation
- Guaranteed availability of high-purity industrial gases
- Product available in liquid phase for storage during maintenance operations
- Low energy consumption
- Short delivery time
Product Parameters
| Gas production m³/h | Oxygen concentration% | Oxygen pressure Mpa | Power 220V Power/kw | Host weight/kg | Dimensions/mm | Air loss factor | Number of bottles per day 40L/120-150kg |
|---|---|---|---|---|---|---|---|
| 3 | 93±3 | 0.4±0.1 | 0.2 | 600 | 15009001500 | 13.5 | 12-15 |
| 5 | 93±3 | 0.4±0.1 | 0.2 | 900 | 16009001500 | 13.5 | 20-24 |
| 10 | 93±3 | 0.4±0.1 | 0.2 | 1200 | 16009001900 | 13.5 | 40-48 |
| 20 | 93±3 | 0.4±0.1 | 0.2 | 1500 | 190010002180 | 13.5 | 80-96 |
| 30 | 93±3 | 0.4±0.1 | 0.2 | 2000 | 200011002180 | 13.5 | 120-154 |
| 40 | 93±3 | 0.4±0.1 | 0.2 | 2500 | 260012002300 | 13.5 | 160-192 |
| 50 | 93±3 | 0.4±0.1 | 0.5 | 2800 | 180015002400+800 | 13.5 | 200-240 |
| 60 | 93±3 | 0.4±0.1 | 0.5 | 3200 | 180015002600+800 | 13.5 | 240-184 |
| 70 | 93±3 | 0.4±0.1 | 0.5 | 3500 | 180016002800+800 | 13.5 | 280-236 |
| 80 | 93±3 | 0.4±0.1 | 0.5 | 4000 | 180016002900+1000 | 13.5 | 320-394 |
| 90 | 93±3 | 0.4±0.1 | 0.5 | 4800 | 200016002800+1000 | 13.5 | 360-432 |
| 100 | 93±3 | 0.4±0.1 | 0.5 | 5800 | 220016002900+1000 | 13.5 | 400-480 |
| 120 | 93±3 | 0.4±0.1 | 0.5 | 6500 | 240016003100+1000 | 13.5 | 480-576 |
Working Principle
The VPSA oxygen production system mainly consists of a blower, vacuum pump, switching valve, adsorber, and oxygen balance tank. The raw air is pressurized by a Roots blower and enters the adsorber filled with oxygen molecular sieves, where moisture, carbon dioxide, and nitrogen are adsorbed to produce oxygen. When adsorption reaches a certain degree, a vacuum pump evacuates the system, extracting and discharging adsorbed components into the atmosphere while regenerating the adsorbent. This process is automatically controlled by PLC and switching valve system.
Applications
Industrial oxygen generator used for aquaculture, welding, cutting, or feeding oxygen to ozone machines.
- Medical: Can be configured to fill hospital pipelines directly with filling ramp backup. Oxygen cylinders can be filled simultaneously or during low consumption periods.
- Metallurgy: Used for anneal protection, agglomeration protection, nitrogenizing, furnace washing and blowing. Applications include metal heat treatment, powder metallurgy, magnetic materials, copper processing, metallic mesh, galvanized wire, and semiconductors.
- Chemical and new material industries: For chemical material gas, pipeline blowing, gas replacement, gas protection, and product transport. Used in chemicals, urethane elastic fiber, rubber, plastic, tires, polyurethane, biotechnology, and intermediates.
- Electronic industry: For encapsulation, agglomeration, anneal, deoxidization, and storage of electronic products. Applications include peak welding, reflow welding, crystals, piezoelectricity, electronic porcelain, electronic copper tape, batteries, and electronic alloy materials.
Packaging
| Size | 123 (L) * 456 (W) * 789 (D) |
| Weight | 1.2 T |
| Packaging Details | Standard packaging is wooden box (Size: L*W*H). For European exports, wooden boxes are fumigated. If container space is limited, we use PE film or accommodate special customer requests. |
In addition to PSA Oxygen Generators, we also produce VPSA Oxygen Generators, storage tanks, heat exchangers and other products. For inquiries about VPSA Oxygen Systems or other products, please contact us at info@gneeheatex.com. We look forward to serving you.
