Small Stainless Steel PSA Nitrogen Generator N2 Gas Making Machine with Lower Maintenance Cost
Ideal for food packaging and industrial applications, this Pressure Swing Adsorption (PSA) Nitrogen Generator efficiently produces high-purity nitrogen from compressed air using advanced physical adsorption technology.
- Automated inflation system with memory function
- User-friendly digital display with unit conversion
- Produces nitrogen with purity up to 96%
- Extended service life with AB twin tower CMS-260 activated carbon molecular sieve
- Includes 20L gas storage tank and 10-meter inflation tube
- Dual-stage filtration system for optimal air quality
| Output (Nm³/h) | Effective Gas Consumption (Nm³/min) | Air Purification System | Import/Export Caliber (mm) |
|---|---|---|---|
| 10 | 0.45 | CJ-1 | DN74 | DN15 |
| 20 | 0.92 | CJ-1 | DN25 | DN25 |
| 30 | 1.3 | CJ-2 | DN25 | DN25 |
| 40 | 1.8 | CJ-2 | DN32 | DN25 |
| 60 | 2.2 | CJ-3 | DN32 | DN25 |
| 80 | 3.5 | CJ-6 | DN40 | DN32 |
| 100 | 4.14 | CJ-6 | DN40 | DN32 |
The PSA nitrogen generation process uses clean, dry compressed air and a high-efficiency carbon molecular sieve to selectively adsorb oxygen, separating it from nitrogen. The system operates through alternating adsorption and regeneration cycles across twin towers to produce continuous nitrogen flow.
| Dimension (L×W×D) | Weight | Packaging Details |
|---|---|---|
| 123 × 456 × 789 cm | 1.2 Tons | Standard wooden crate packaging. European shipments include fumigation. Custom packaging available upon request. |
We also manufacture VPSA Oxygen Generators, PSA Oxygen Generators, storage tanks, and heat exchangers. For inquiries about our nitrogen systems or other products, please contact us at info@gneeheatex.com.
