Carbon Steel Shell Tube Heat Exchanger Condenser 3.0mpa Q345R
Good sell thermal oil carbon steel shell tube heat exchanger
Description
Shell-and-tube heat exchangers are general-purpose process equipment for heat exchange, which can be used in industrial sectors such as chemical petroleum, electric power light industry, and aviation heating, especially in petroleum refining and chemical processing units.
Parameter
| Design Specification | ||
| Parameter | Shell side | Tube side |
| Fluid | Steam, liquid... | Steam, liquid... |
| Design pressure | -0.1~3.0MPa | -0.1~3.0MPa |
| Working pressure(shell side) | As required | As required |
| OPER.TEMP.(IN/OUT) | -19~500℃ | -19~500℃ |
| OPER.TEMP.(IN/OUT) | As required | As required |
| Material | Q345R/SS304/SS316L... | Q345R/SS304/SS316L... |
| Joint EFF | 0.85 | 0.85 |
| Trans Surface(O.D)m² | 10-500 | |
Feature
Shell and tube heat exchanger is a widely used in chemical and alcohol production heat exchanger, mainly composed of shell, tube plate, heat exchange tube, sealing head, baffle, etc., material optional stainless steel, dual-phase stainless steel, titanium (Ti), carbon steel...... During the heat exchanger, a stream of fluid enters the joint of the sealing head, flows through the tube, and exits and exits the other joint of the housing. The joint from the other tube of the shell is called the shell side.
Advantage
The shell and tube heat exchanger produced by our company does not use the traditional heat exchange structure of cold oil going through the tube and hot oil going through the shell, but adopts the combination of casing structure, which can effectively solve the problem of blockage, thus improving the heat exchange efficiency and reducing the energy consumption. The integral shell and tube heat exchanger has the advantages of superior performance, easy operation and maintenance and light weight.
