Led Driver 110v 220v Ac To Dc 24V LED Power Supply 15a 360w For Led Light
LED Driver 110V 220V Ac To Dc 24V 15a 360W Led Switching Power Supply For LED Light
Now higher current does make the LED brighter, but it also will eventually over-drive the LED. See Figure 2 for Cree’s specifications of the maximum forward current and the de-rating curves in different ambient temperature conditions. In the example above we would still be alright driving the XP-G2 LED at 700mA, however, if you didn’t have a current limiting device, the LED would draw more current as it’s electrical characteristics changed due to temperature increase. This would eventually push the current way above the limit…especially in hotter environments. The excess forward current would result in extra heat within the system, cut down on the LEDs lifespan, and eventually ruin the LED. We call this thermal runaway which is explained in more detail here. This is the reason the preferred method of powering high powered LEDs is with a constant current LED driver. With a constant current source, even as the voltage changes with temperature the driver keeps the current steady while not over driving the LED and preventing thermal runaway.
Specification
| Product Name: | switching power supply | Output Current: | 5a, 5a |
| Output Power: | 51 - 100W, 60w | Protections: | Short Circuit Overtemp Overload Overvolt |
| Output Type: | Single | type: | Constant Voltage |
| Input Voltage: | 100-240v, 100-240VAC | Model Number: | 60w |
| Output Voltage: | 12V, 12v/24v | Carton: | 50pcs/carton |
| Output Frequency: | 47-63HZ, 47-63HZ | warterproof: | ip68 |
| DC output voltage | 5V | 12V | 15V | 24V |
| Output voltage tolerance | ±2% | ±1% | ±1% | ±1% |
| Rated output current | 24A | 10A | 8A | 5A |
| Output current range | 0-24A | 0-10A | 0-8A | 0-5A |
| Ripple and noise | 50mVp-p | 100mVp-p | 100mVp-p | 100mVp-p |
| Inlet stability | ±0.5% | ±0.5% | ±0.3% | ±0.2% |
| Load stability | ±1% | ±0.5% | ±0.3% | ±0.2% |
| DC output power | 120W | 120W | 120W | 120W |
| Efficiency | 79% | 84% | 85% | 85% |
| Output voltage adjustment range | ±15% | ±15% | ±15% | ±15% |
| AC input voltage range | 110-220V | |||
| Input current | 0.6A/115V 0.35A/230V | |||
| AC impulse current | Cold-start current 15A/115V 30A/230V | |||
| Leakage current | <0.75mA/240VAC | |||
| Overload protection | 105%~150% Type,PULSING HICCUP SHUTDOWN,Reset,auto recovery | |||
| Over-voltage protection | 115%~135% rated output power | |||
| Temperature coefficient | ±0.03%°C(0~50°C) | |||
| Setup rise hold up time | 800ms,50ms,20ms/115VAC 300ms,50ms,80ms/230VAC | |||
| Vibration | 10~500Hz,2G 10min./1cycle,Period for 60min,Each axes | |||
| Withstand voltage | I/P-O/P:2.5KVAC I/P-FG:2KVAC O/P-FG:0.5KVAC | |||
| Isolation resistance | I/P-O/P I/P-FG O/P-FG:500VDC/100MΩ | |||
| Working temperature and humidity | -10°C~+60°C,20~90%RH | |||
| Store temperature and humidity | -20°C~+85°C,10~95%RH | |||
FAQ
Q1.Can I have a sample order for led driver?
A:Yes,we welcome sample order to test and check quality.Mixed samples are acceptable.
Q2.Do you have any MOQ limit for the led driver?
A:Low MOQ,1PCS for sample checking is available.
Q3:Is it OK to print my logo on led product?
A:Yes.Please inform us formally before our production and confirm the design firstly based on our sample.
Q4:Do you offer guarantee for the products?
A:Yes,we offer 2years warranty to our products.
Q5: How to deal with the faulty?
A:Firstly, Our products are produced in strict quality control system and the defective rate will be less than 0.2%.
Secondly, during the guarantee period, we will send new lights with new order for small quantity. For defective batch products, we will repair them and resend them to you or we can discuss the solution including re-call according to real situation.
