Aluminum Shell 12V 20A LED Power Supply 240W 24V 10A Power Supply
Aluminum Shell 12V 20A Led Power Supply 240W 24V 10A Power Supply
When do I use a constant voltage LED driver?
The above example is with high powered LEDs and on a smaller scale as we only talked of using one LED. With lighting in the real world, it isn’t convenient or economical to build everything by hand from a single diode, LEDs are usually used together in series and/or parallel circuits to create the desired outcome. Fortunately for lighting designers, manufacturers have introduced many LED products to the market that have multiple LEDs already assembled together like LED rope light, LED strips, LED bars, etc.
The most common LED strips are designed with a group of LEDs in series with a current-limiting resistor in line with them. The manufacturers make sure the resistors are of the right value and in the right position so that the LEDs on the strips will be less prone to the variation of the voltage source as we talked of with the XP-G2. Since their current is already being regulated, all they need is a constant voltage to power the LED(s).
When LEDs or an array of LEDs are constructed like this they will typically state a voltage to be run at. So if you see that your strip takes 12VDC, don’t worry about a constant current driver, all you will need is a 12VDC constant voltage source as the current is already being regulated by on board circuitry that the manufacturer has built in.
Specification
| Product Name | Switching Power Supply |
| Model No. | LSN-226 |
| Input | 90-130V AC / 180-240V AC |
| Output | 12V 20A (5V48A / 15V16A / 24V10A) |
| Power | 240W |
| Working environment | -20℃ ~ +50℃ 20% ~ 90%RH(No condensation) |
| Length*Width*Height | 215*114*49mm |
| Warranty | 1-3 Years |
| Material | New PC material, using imported energy-saving IC identification chip |
| Advantage | Good safety performance and high reliability |
| Protection | Short circuit protrction, overload protrction, over voltage protrction, over temperature protrction |
| Widely used in | Security monitoring, industrial control, LED lighting |
Our Services
1. Professional Service Team and Development Team.
2. High Quality Product and Reasonable Price.
3. OEM Service Logo and Packing.
4. Three Packing Methods.
5. 7-15 Days, Fast and Safe Delivery.
6. 12-24 Months After - Sale Guaranteed.
| DC output voltage | 5V | 12V | 15V | 24V |
| Output voltage tolerance | ±2% | ±1% | ±1% | ±1% |
| Rated output current | 24A | 10A | 8A | 5A |
| Output current range | 0-24A | 0-10A | 0-8A | 0-5A |
| Ripple and noise | 50mVp-p | 100mVp-p | 100mVp-p | 100mVp-p |
| Inlet stability | ±0.5% | ±0.5% | ±0.3% | ±0.2% |
| Load stability | ±1% | ±0.5% | ±0.3% | ±0.2% |
| DC output power | 120W | 120W | 120W | 120W |
| Efficiency | 79% | 84% | 85% | 85% |
| Output voltage adjustment range | ±15% | ±15% | ±15% | ±15% |
| AC input voltage range | 110-220V | |||
| Input current | 0.6A/115V 0.35A/230V | |||
| AC impulse current | Cold-start current 15A/115V 30A/230V | |||
| Leakage current | <0.75mA/240VAC | |||
| Overload protection | 105%~150% Type,PULSING HICCUP SHUTDOWN,Reset,auto recovery | |||
| Over-voltage protection | 115%~135% rated output power | |||
| Temperature coefficient | ±0.03%°C(0~50°C) | |||
| Setup rise hold up time | 800ms,50ms,20ms/115VAC 300ms,50ms,80ms/230VAC | |||
| Vibration | 10~500Hz,2G 10min./1cycle,Period for 60min,Each axes | |||
| Withstand voltage | I/P-O/P:2.5KVAC I/P-FG:2KVAC O/P-FG:0.5KVAC | |||
| Isolation resistance | I/P-O/P I/P-FG O/P-FG:500VDC/100MΩ | |||
| Working temperature and humidity | -10°C~+60°C,20~90%RH | |||
| Store temperature and humidity | -20°C~+85°C,10~95%RH | |||
FAQ
Q1. Are you manufacturer? If yes, in which city?
A1:Yes, our factory locates at shenzhenbaoan district . Warmly welcome your visiting. Please kindly tell me your schedule before you come here, we will prepare to pick you up.
Q2. What is the warranty for the adapter/charger?
A2: All our products have 12-24 months warranty.
Q3. Do you offer free samples?
A3: Yes. Free samples are available,but the shipping cost should be on the buy's side.
Q4. Does the adapter/charger are original?
A4: Yes, all of our laptop adapters are 100% original brand new.
Q5. Do you provide high copy adapter/charger?
A5: Yes, we provide all brand original and OEM adapter/charger to meet different requirements from different buyers.
Q6. what is your delivery date?
A6: The product delivery date is about 7-15 days after receipt of payment according to your order quantity.
