44W DALI Power Supply PUSH LED Down Light Panel Light Dimmable Driver
44W DALI PUSH Led Down Light Panel Light Dimmable Driver
Features:
·Output constant voltage
·Range: 100-277VAC
·Built-in active PFC function
·Efficiency up to 81%
·Protections: short circuit/over load/ over temperature
·Cooling by free air convection
·IP20 design for indoor installation.
·Dimming function: Built in DALI interface dimming function conform to DALI Protocol IEC62386
·Push dimming function
·Dimming range: 0-100%, LED start at 0.1% possible
·Suitable for intelligent LED lighting
Product Specification
| Technical Norm | ||||
| Features | Output Type | Constant Current | ||
| Dimming Type | Dali-2 & PUSH | |||
| Dimming Range | 1-100% | |||
| Dimming Depth | 0.10% | |||
| Output Features | Isolation | |||
| Insulation Class | Class II | |||
| Input | Voltage Range | AC220-240V | ||
| DC220-240V | ||||
| Limited Voltage | 264VAC | |||
| Power Factor | >0.95 | |||
| T.H.D | <15% | |||
| Output | Current Ripple | ±5% | ||
| PstLM | <1 | |||
| SVM | <0.4 | |||
| Current Accuracy | ±5% | |||
| Power-on Time | <0.5s | |||
| Protection | Short Circuit | constant voltage mode, recover automatically after fault condition is removed | ||
| Over Loading | ≤120% constant voltage limiting, recover automatically after fault condition is removed | |||
| Over Temperature | 100℃±10℃ | |||
| Shut down o/p voltage, recovers automatically after temperature goes down | ||||
| Others | Ta | -20℃~50℃ | ||
| Tc | 85℃ | |||
| IP rating | IP20 | |||
| Life span | 50000hours | |||
| Warranty | 5 years | |||
| Notes | 1. All parameters NOT specially mentioned are measured at 230VAC input , rated load and 25℃of ambient temperature. | |||
| 2. Tolerance: includes set up tolerance, line regulation and load regulation . | ||||
| 3. The power supply is considered as a component that will be operated in combination with final Equipment. Since EMC performance will be affected by the complete installation, the final equipment manufactures must be-qualify EMC Directive on the complete installation again. | ||||
What is your advantages?
1. OEM/ODM is welcome, over 15years of experence.
2. High efficiency, low power consumption led light driver.
3. CE(TUV),RoHs, SAA, C-tick,RCM, FCC and ETL approved.
4. Stable quality, burn-in tests with 100% full load for more than 4 hours.
5. Over-heat, over-load, short-circuit & open-circuit protection.
6. Offer 3 or 5 years warranty and maintain our repair rate below 0.3%.
7. We will apply 0.3% spare parts on bulk orders.
8. Professional team will follow the whole after-sale.
from 5W to 600W C.V. 12VDC 24VDC 36VDC 48VDC ;3W to 200W C.C.
5 years warranty
Dimming range 0-100%
No noise , Flicker free
High frequency exemption level, High PF (PF>0.95)
Aluminum shell & plastic shell for output and indoor use (IP66 Waterproof ,IP20)
Slim ,linear led driver
All-round protection-Short circuit,over load, over-temperature
FAQ
Q1. How can I obtain a sample?
A: Contact us and we will handle it.
Q2. Can I add my own logo?
A: Sure, we offer flexible OEM & ODM solutions. You can have your logo on the product, packaging, user manual, you name it.
Q3. What is your MOQ?
A: None.
Q4. What is the production lead time?
A: We keep a ready to ship stock level on certain product lines, others usually take 2-4 weeks.
Q5. What is the delivery time?
A: We offer shipping via sea, road, rail and air. The shipment time depends on the choice of transportation.
Q6. What is the warranty?
A: We offer a minimum two years warranty along with a comprehensive after sale service.
Q7. Are the products certified?
A: Yes, we are fully certified for the EU and UK markets. If you require any other forms of certificates, do get in touch.
