X165CrMoV 12 W-Nr 1.2601 AISI D2 UNS T30402 JIS SKD11 Mould Steel
X165CrMoV 12, W-Nr 1.2601, AISI D2, UNS T30402, JIS SKD11 Mould Steel
Describe
X165CrMoV12 1.2601 is a German cold work tool alloy steel material grade. It is impact resistant steel. It belongs to the DIN 17350 standard. Numerical grade material number 1.2601. Metal steel grade W-Nr X165CrMoV12 It is a die steel used for extrusion dies and hot casting dies. Such as aluminum production, aluminum cutting die.
Size Range
- Material:Metal, Structural Steel Round Bar, P20+S Tool Steel Round Bar
- Shape:Tool Steel
- Round bar / Wire rod (Diameter): 5.5mm to 800mm
- Square bar / Flat bar: 3mm to 800mm
- Forging piece: stepped shafts with flanks / discs /tubes /slugs /donuts /cubes /other different shapes based on OEM.
- Heavy/middle plate via hot rolled: T6 - 200mm X W10 - 1500mm X L1000-12000mm
- Length: Fixed length or random length or based on the customer's special requirement.
Chemical Composition and standard
| Grade |
X165CrMoV 12 W-Nr 1.2601 |
AISI D2 UNS T30402 |
JIS SKD11 |
| standard | DIN 17350-1980 | ASTM A681-2008(R2015) | JIS G 4404-2015 |
| Chemical Composition (weight%) |
C(％): 1.55~1.75 Mn(％): 0.2~0.4 Ni(％): - - |
C(％): 1.4~1.6 Si(％): 0.1~0.6 Mn(％): 0.1~0.6 S(％)≤: 0.03 Ni(％): - - |
C(％): 1.4~1.6 Si(％): ≤0.4 Mn(％): ≤0.6 S(％)≤: 0.03 Ni(％): - - |
| Other | W: 0.4~0.6, V: 0.1~0.5 | V: 0.5~1.1, Ni+Cu: ≤0.75 | V: 0.2~0.5 |
Mechanical Properties
X165CrMoV 12, W-Nr 1.2601 mould Steel Mechanical Properties
| Tensile strength,Rm/MPa: | ≥662 |
| Yield strength,Rp/MPa: | ≥641 |
| Elongation/%: | 14 |
| Reduction of area, ψ/%: | --- |
| Impact, KV /J: | 23 |
Applications
Cutting tools, Stamping, Woodworking, Wire drawing, Deep drawing and Stamping tools, Cold working
roll, Gage
FAQ
Q: How do you control the quality?
A: We have professional inspectors to analyze the chemical composition of raw materials and test the finished products in strict accordance with the standards stipulated in the contract. In this process, the inner and outer surfaces, the appearance of both ends, bending, set length, outer diameter and Wall thickness will be checked one by one. You can rest assured that all products you receive from us are reliable.
Q: Do you accept customization?
A: Yes. If you have special requirements for products or packaging, we can make them for you.
Q: Can you accept trial orders?
A: Our MOQ is usually 1 ton. However, if you want to place an order as the start of our cooperation, we can accept smaller quantities at the first time. Of course, after the start, we will have further and longer cooperation.
Q: How do I get samples?
A: Free samples are available for your inspection and testing, DHL/FedEx/UPS accounts can be used for sampling, and the courier fee is borne by you.
