AMS 5510 Stainless Steel Round Bar AMS 5510E Metal Flat Bar
AMS 5510 Stainless Steel Round Bar AMS 5510E Metal Flat Bar
Product introduction
As a widely used steel, it has good corrosion resistance, heat resistance, low temperature strength and mechanical properties; good hot workability such as stamping and bending, and no heat treatment hardening (use temperature -196 ° C ~ 800 ° C). Corrosion resistance in the atmosphere, if it is an industrial atmosphere or heavily polluted area, it needs to be cleaned in time to avoid corrosion. Suitable for food processing, storage and transportation. Has good processability and weldability.
Size Range
| Round bar / Wire rod (Diameter): | 3.0mm to 1000mm |
| Square bar / Flat bar: | 3.5mm to 1000mm |
| Forging piece: |
Stepped shafts with flanks / discs /tubes |
| Heavy/middle plate via hot rolled: | T6 - 150mm X W10 - 1400mm X L1000-8000mm |
|
Sheet steel via cold rolled: |
T0.5 - 5mm X W6 - 1000mm X L1000 - 1000mm |
|
Steel strip via cold rolled: |
T0.1 - 4.50mm X W5 - 180mm X L (or in coil form) |
| Length | Fixed length or random length or based on the customer's special requirement. |
Chemical Composition and standard
| Grade |
AMS 5510E |
| standard | SAE AMS 5501E-2013 |
| Chemical Composition (weight%) |
C (％): ≤ 0.08
Mn (％): ≤ 2.00 Si (％): ≤ 1.00 P (％)≤: 0.040
S (％)≤: 0.030 Cr (％): 18.0 ~ 20.0 Ni (％): 8.00 ~ 11.00 Mo (%): ≤ 0.75 Cu (%): ≤ 0.75 Fe (%): Remainder.
|
Mechanical Properties
AMS 5510E Stainless Steel Mechanical Properties
| Tensile strength,Rm/MPa: | 862 |
| Yield strength,Rp/MPa: | 517 |
| Elongation/%: | 15 |
| Reduction of area, ψ/%: | -- |
| Impact, KV /J: | -- |
| Annealed hardness HBS: | -- |
