Product introduction
AMS 5653 is a molybdenum-containing stainless steel. Because the steel contains molybdenum, the overall performance of this steel is better than that of 310 and 304 stainless steel. Under high temperature conditions, when the concentration of sulfuric acid is lower than 15% or higher than 85%, AMS 5653 stainless steel has a wide range of properties. use. AMS 5653 stainless steel also has good resistance to chloride attack, so it is usually used in marine environments.
AMS 5653 stainless steel has a maximum carbon content of 0.03 and can be used in applications where annealing after welding cannot be performed and where maximum corrosion resistance is required.
Size Range
| Round bar / Wire rod (Diameter): | 4.0mm to 900mm |
| Square bar / Flat bar: | 3.0mm to 1000mm |
| Forging piece: |
Stepped shafts with flanks / discs /tubes |
| Heavy/middle plate via hot rolled: | T6 - 100mm X W10 - 1300mm X L2000-10000mm |
|
Sheet steel via cold rolled: |
T0.3 - 5mm X W6 - 1000mm X L1000 - 10000mm |
|
Steel strip via cold rolled: |
T0.1 - 4.0mm X W5 - 150mm X L (or in coil form) |
| Length | Fixed length or random length or based on the customer's special requirement. |
Chemical Composition and standard
| Grade |
AMS 5653 |
| standard | SAE AMS 5653H-2012 |
| Chemical Composition (weight%) |
C (％): ≤ 0.030
Mn (％): 1.25 ~ 2.00 Si (％): ≤ 1.00 P (％)≤: 0.040
S (％)≤: 0.030 Cr (％): 16.0 ~ 18.0 Ni (％): 10.0 ~ 14.0 Mo (%): 2.00 ~ 3.00
Cu (%): ≤ 1.00Fe (%): Remainder |
Mechanical Properties
AMS 5653 Stainless Steel Mechanical Properties
| Tensile strength,Rm/MPa: | ≥482 |
| Yield strength,Rp/MPa: | ≥172.4 |
| Elongation/%: |
Hot Finished ≥40 Cold Finished ≥30
|
| Reduction of area, ψ/%: |
Hot Finished ≥50 Cold Finished ≥40
|
| Impact, KV /J: | -- |
| Annealed hardness HBS: | ≤255 |
