Production Information
AMS 5664 is a nickel-chromium alloy, precipitation hardenable, with high creep rupture strength at elevated temperatures up to about 1300 °F (700 °C). AMS 5664 has a poor age hardening response, so annealing and welding will not spontaneously harden during heating and cooling. This alloy has excellent weldability compared to aluminum and titanium hardened nickel-based superalloys.
Size Range
| Round bar / Wire rod (Diameter): | 3.0mm to 1100mm |
| Square bar / Flat bar: | 5.0mm to 900mm |
| Forging piece: |
Stepped shafts with flanks / discs /tubes |
| Heavy/middle plate via hot rolled: | T6 - 100mm X W10 - 1000mm X L1500-10000mm |
|
Sheet steel via cold rolled: |
T0.5 - 5.0mm X W6 - 1000mm X L1000 - 10000mm |
|
Steel strip via cold rolled: |
T0.1 - 5.0mm X W5 - 150mm X L (or in coil form) |
| Length | Fixed length or random length or based on the customer's special requirement. |
Chemical Composition and standard
| Grade |
AMS 5661E |
| standard | SAE AMS 5661E-1995 |
| Chemical Composition (weight%) |
C (％): ≤ 0.08 Ti (%): 0.65 ~ 1.15
Mn (％): ≤ 0.35 Al (%): 0.20 ~ 0.80 Si (％): ≤ 0.35 B (%): ≤ 0.006 P (％)≤: 0.015 Nb (%): 4.75 ~ 5.50 S (％)≤: 0.015 Cu (%): ≤ 0.30 Cr (％): 17.0 ~ 21.0 Co (%): ≤ 1.00 Ni (％): 50.0 ~ 55.0 Ta (%): ≤ 0.05 Mo (%): 2.80 ~ 3.30 Fe (%): Remainder |
Mechanical Properties
AMS 5664 Stainless Steel Mechanical Properties
| Tensile strength,Rm/MPa: | ≥1241 |
| Yield strength,Rp/MPa: | ≥1304 |
| Elongation/%: |
≥12
|
| Reduction of area, ψ/%: |
≥15
|
| Impact, KV /J: | -- |
| Annealed hardness HBS: | ≤341 |
