ASTM F6 B UNS S41026 Alloy Steel Flat Bar X15CR13 W-NR 1.4024 ISO X12CRMO12-6 Strip
ASTM F6 B UNS S41026 Alloy Steel Flat Bar X15CR13 W-NR 1.4024 ISO X12CRMO12-6 Strip
Size Range
| Round bar / Wire rod (Diameter): | 3.0 mm to 800 mm |
| Square bar / Flat bar: | 5.0 mm to 1000 mm |
| Forging piece: |
Stepped shafts with flanks/discs /tubes |
| Heavy/middle plate via hot rolled: | T5 - 500 mm X W5 - 1000 mm X L1000-10000 mm |
|
Sheet steel via cold rolled: |
T0.5 - 10.0 mm X W10 - 1000 mm X L1000 - 10000 mm |
|
Steel strip via cold rolled: |
T0.5 - 8.0 mm X W10 - 1000 mm X L (or in coil form) |
| Length | Fixed length or random length or based on the customer's special requirement. |
Chemical Composition and standard
|
F6 b/S41026 |
X15Cr13/1.4024 | X12CrMo12-6 |
| ASTM A182/A182M(2004) | DIN 10088-1(2005) | ISO 4956(1984) |
|
C(％): ≤0.15 |
C(％): 0.12~0.17 |
C(％): 0.08~0.16 |
| SUS 410J1 / STS410J1 | 420S29 | |
|
JIS G4303(2005)/KSD3706(2006) |
BS EN 10088-2(2005) | |
|
C: 0.08~0.18 Si: ≤0.60 Mn: ≤1.00 P: ≤0.040 S: ≤0.040 Cr: 11.5~14.0 Ni: ≤0.60 Mo: 0.30~0.60 |
C: 0.14~0.20 Si: ≤1.00 Mn: ≤1.00 P: ≤0.040 S: ≤0.030 Cr: 11.5~13.5 Ni: ≤1.00 Mo: --
|
Mechanical Properties
X15CR13/1.4024 Alloy Round Bar Mechanical Properties
| Tensile strength, Rm/MPa: | ≤730 |
| Yield strength, Rp/MPa: | -- |
| Elongation/%: | -- |
| Reduction of area, ψ/%: | -- |
| Impact, KV /J: | -- |
| Annealed hardness HRC: | ≤ 220 |
