W-Nr 1.4571 X6CrNiMoTi 17-12-2 Stainless Steel Round Bar 320S31 Z6CNDT 17-12
W-Nr 1.4571 X6CrNiMoTi 17-12-2 Stainless Steel Round Bar 320S31 Z6CNDT 17-12 Alloy Steel Bar
Description
1.4571 Stainless steel is austenitic stainless steel with high strength and good corrosion resistance, so it is suitable for chemical industry, nuclear energy, vacuum technology, submarine construction, furnace construction, trans-sulfide, textile, dye, photochemical and pharmaceutical industries. This material is also gradually being used in exhaust technology.
- Material:Metal, Alloy Round Bar, W-Nr 1.4571 X6CrNiMoTi 17-12-2 Stainless Steel Round Bar
- Shape:Stainless Steel Round Bar
- Round bar / Wire rod (Diameter): 3.5mm to 800mm
- Square bar / Flat bar: 5mm to 800mm
- Forging piece: stepped shafts with flanks / discs /tubes /slugs /donuts /cubes /other different shapes based on OEM.
- Heavy/middle plate via hot rolled: T5 - 200mm X W10 - 1500mm X L1000-12000mm
- Sheet steel via cold rolled: T0.5 - 6mm X W6 - 1000mm X L1000 - 2000mm
- Steel strip via cold rolled: T0.1 - 5mm X W5 - 200mm X L (or in coil form)
- Length: Fixed length or random length or based on the customer's special requirement.
Products Details
Chemical Composition (weight%):
| X6CrNiMoTi 17-12-2/1.4571 | ISO X6CrNiMoTi 17-12-2 |
|
EN 10088-1-2005 NF EN 10088-1(2005) BS EB 10088-1(2005) |
ISO/TS 15510(2003) |
|
C(％): ≤0.08
Si(％): ≤1.0 Mn(％): ≤2.0 P(％): ≤0.045
S(％): ≤0.015
Cr(％): 16.5~18.5 Ni(％): 10.5~13.5 Mo(％): 2.0~2.50 Ti(％): 5xC~0.70 |
C(％): ≤0.08
Si(％): ≤1.0 Mn(％): ≤2.0 P(％): ≤0.045
S(％): ≤0.030
Cr(％): 16.5~18.5 Ni(％): 10.5~13.5 Mo(％): 2.0~2.50 Ti(％): 5xC~0.70 |
| Z6CNDT 17-12 | 320S31 |
|
NF A 35-574(1990)
|
BS 970-3-1991 |
|
C(％): ≤0.08
Si(％): ≤0.75 Mn(％): ≤2.0 P(％): ≤0.040
S(％): ≤0.015
Cr(％): 16.0~18.0 Ni(％): 10.5~13.0 Mo(％): 2.0~2.50 Ti(％): 5xC~0.60 |
C(％): ≤0.08
Si(％): ≤1.0 Mn(％): ≤2.0 P(％): ≤0.035
S(％): ≤0.020
Cr(％): 16.5~18.5 Ni(％): 11.0~14.0 Mo(％): 2.0~2.50 Ti(％): 5xC~0.80 |
Mechanical Properties Under Final Heat Treatment:
TS, σb/≥MPa: 200
YS, σ0.2/MPa: 500~700
EL, δ 5≥(％): 40
Reduction of area, ψ/%: ≥50
Impact, AKV≥/J: --
Hardness HB: ≤215
FAQ
Q: How do you control the quality?
A: We have professional inspectors to analyze the chemical composition of raw materials and test the finished products in strict accordance with the standards stipulated in the contract. In this process, the inner and outer surfaces, the appearance of both ends, bending, set length, outer diameter and Wall thickness will be checked one by one. You can rest assured that all products you receive from us are reliable.
Q: Do you accept customization?
A: Yes. If you have special requirements for products or packaging, we can make them for you.
Q: Can you accept trial orders?
A: Our MOQ is usually 1 ton. However, if you want to place an order as the start of our cooperation, we can accept smaller quantities at the first time. Of course, after the start, we will have further and longer cooperation.
Q: How do I get samples?
A: Free samples are available for your inspection and testing, DHL/FedEx/UPS accounts can be used for sampling, and the courier fee is borne by you.
