China AISI P91 F91 Alloy Round Bar X10CrMoVNb9-1 W-Nr 1.4903 Stainless True Bar for sale

AISI P91 F91 Alloy Round Bar X10CrMoVNb9-1 W-Nr 1.4903 Stainless True Bar

Name: AISI P91 F91 Alloy Round Bar X10CrMoVNb9-1 W-Nr 1.4903 Stainless True Bar
Brand: Mianyang Baoheng New Material Technology Co.,Ltd

Price Negotiable

Price: Negotiations

MOQ: 1000kg

Delivery Time: Ex-stock for delivery: 3-7 days Production lead time: 30-60 days

Brand: PANGANGGROUP,TISCO,ANSTEEL,BAOSTEEL

Product Description

AISI P91 F91 Alloy Round Bar X10CrMoVNb9-1 W-Nr 1.4903 Stainless True Bar

Size Range

Round bar / Wire rod (Diameter):

5.5 mm to 1500 mm

Square bar / Flat bar:

3.5 mm to 1000 mm

Forging piece:

Stepped shafts with flanks/discs /tubes /slugs /donuts /cubes /other different shapes based on OEM.

Heavy/middle plate via hot rolled:

T3.5 - 100 mm X W5 - 1000 mm X L1000-10000 mm

Sheet steel via cold rolled:

T0.5 - 10.0 mm X W5 - 1000 mm X L1000 - 10000 mm

Steel strip via cold rolled:

T0.5 - 10.0 mm X W5 - 1000 mm X L (or in coil form)

Length:

Fixed length or random length or based on the customer's special requirement.

Chemical Composition and standard

P91	F91(Type 1)	F91(Type 2)
ASME SA-335/SA-335M-2021	ASME SA-182/SA-182M-2019	ASME SA-182/SA-182M-2019
C(％): 0.08~0.12 Si(％): 0.20~0.50 Mn(％): 0.30~0.60 P(％)≤: 0.02 S(％)≤: 0.01 Cr(％): 8.0~9.5 Ni(％): ≤0.4 Mo(％): 0.85~1.05 N(%): 0.03~0.07 Ti(%): ≤0.01 V(%): 0.18~0.25 Nb(%): 0.06~0.10	C(％): 0.08~0.12 Si(％): 0.20~0.50 Mn(％): 0.30~0.60 P(％)≤: 0.02 S(％)≤: 0.01 Cr(％): 8.0~9.5 Ni(％): ≤0.4 Mo(％): 0.85~1.05 N(%): 0.03~0.07 Ti(%): ≤0.01 V(%): 0.18~0.25 Nb(%): 0.06~0.10 Zr(%): ≤0.01 Al(%): ≤0.02	C(％): 0.08~0.12 Si(％): 0.20~0.40 Mn(％): 0.30~0.50 P(％)≤: 0.02 S(％)≤: 0.005 Cr(％): 8.0~9.5 Ni(％): ≤0.2 Mo(％): 0.85~1.05 Cu(％): ≤0.1 As(％): ≤0.01 N(%): 0.035~0.07 Ti(%): ≤0.01 W(％): ≤0.05 V(%): 0.18~0.25 Nb(%): 0.06~0.10 Zr(%): ≤0.01 Al(%): ≤0.02 Sn(%): ≤0.01 Sb(%): ≤0.003 B(％): ≤0.001
F91(Product)	X10CrMoVNb9-1/1.4903
ASME SA-182/SA-182M-2019	IN 10222-2-2017
C(％): 0.07~0.13 Si(％): 0.20~0.40 Mn(％): 0.30~0.50 P(％)≤: 0.02 S(％)≤: 0.005 Cr(％): 8.0~9.5 Ni(％): ≤0.2 Mo(％): 0.85~1.05 Cu(％): ≤0.1 As(％): ≤0.01 N(%): 0.035~0.07 Ti(%): ≤0.01 W(％): ≤0.05 V(%): 0.16~0.27 Nb(%): 0.05~0.11 Zr(%): ≤0.01 Al(%): ≤0.02 Sn(%): ≤0.01 Sb(%): ≤0.003 B(％): ≤0.001 N/Al(％): ≥4.0	C(％): 0.08~0.12 Si(％): ≤0.50 Mn(％): 0.30~0.60 P(％)≤: 0.02 S(％)≤: 0.005 Cr(％): 8.0~9.5 Ni(％): ≤0.3 Mo(％): 0.85~1.05 Cu(%): ≤0.3 N(%): 0.03~0.07 V(%): 0.18~0.25 Nb(%): 0.06~0.10 Al(%): ≤0.04

Mechanical Properties

Tensile strength, Rm/MPa: P91 ≥700, F91 ≥620
Yield strength, Rp/MPa: P91 ≥300, F91 ≥415
Elongation, A/%: P91 ≥20, F91 ≥20
Reduction of area, ψ/%: F91 ≥40
Impact, AKV /J: --
Annealed hardness HBW: F91 190~248
