NiCr15Fe W-Nr 2.4816 Alloy Round Bar Inconel 600 AMS 5665 Sheet Steel
NiCr15Fe W-Nr 2.4816 Alloy Round Bar Inconel 600 AMS 5665 Sheet Steel
Product Information
NiCr15Fe/2.4816 is one of the most popular superalloys on the market. It has proven creep and heat resistance, maintaining good mechanical properties at elevated temperatures. NiCr15Fe/2.4816 has good resistance to many high temperature, aggressive chemicals.
Size Range
Round bar / Wire rod (Diameter): 1.0 mm to 1000 mm
Square bar / Flat bar: 8.0 mm to 1000mm
Forging piece: Stepped shafts with flanks / discs /tubes /slugs /donuts /cubes /other different shapes based on OEM.
Heavy/middle plate via hot rolled: T5 - 200 mm X W3 - 1000 mm X L1000-12000 mm
Sheet steel via cold rolled: T0.5 - 10 mm X W5 - 1000 mm X L1000 - 1000 mm
Steel strip via cold rolled: T0.3 - 8.0 mm X W3 - 200 mm X L (or in coil form)
Length: Fixed length or random length or based on the customer's special requirement.
Chemical Composition and standard
|
NiCr15Fe/2.4816 |
Inconel 600/UNS N06600 | AMS 5665 | JIS NCF600 |
| DIN 17742-2020 |
SAE J 470c-1976 |
SAE AMS 5665N-201 | JIS G 4901-2008 |
|
Mo(%): -- Cu(%): ≤0.5 Ti(%): ≤0.3 Co(%): ≤1.5 Al(%): ≤0.3 B(%): ≤0.006 Fe(%): 6.0~10.0
|
C(％): ≤0.15 Mo(%): -- Cu(%): ≤0.5 Fe(%): 6.0~10.0 |
C(％): ≤0.15 Mo(%): -- Cu(%): ≤0.5 Fe(%): 6.0~10.0 Co(％): ≤1.0 Nb(％): ≤1.0 Ti(％): ≤0.50 Al(％): ≤0.35
|
C(％): ≤0.15 Mo(%): -- Cu(%): ≤0.5 Fe(%): 6.0~10.0 |
NiCr15Fe/2.4816 Mechanical Properties
Tensile strength, σb/Mpa: 550~725
Yield Point, σs/Mpa: 170~345
Elongation, δ/%: 55~35
Reduction of Area,ψ/%: --
Hardness (HB): 65~85
Applications
NiCr15Fe8/2.4816 alloys are used in engine and airframe components such as exhaust liners, turbine seals, furnaces, reactors, and other heat treatment equipment.
