1.4828 DIN X15CrNiSi20-12 Stainless Steel Round Bar Alloy 309 UNS S30900 Plates
1.4828 DIN X15CrNiSi20-12 Stainless Steel Round Bar Alloy 309 UNS S30900 Plates
Product Information
X15CrNiSi20-12/1.4828 steel is produced into coils, bars and tubes in the form of hot-rolled plates to produce special load parts and subclasses that can withstand long-term high temperature.
Size Range
Round bar / Wire rod (Diameter): 5.0 mm to 500 mm
Square bar / Flat bar: 5.0 mm to 500 mm
Forging piece: Stepped shafts with flanks / discs /tubes /slugs /donuts /cubes /other different shapes based on OEM.
Heavy/middle plate via hot rolled: T5 - 1000 mm X W10 - 1000 mm X L800-12000 mm
Sheet steel via cold rolled: T5.0 - 10 mm X W10 - 1000 mm X L100 - 1000 mm
Steel strip via cold rolled: T7 - 10 mm X W10 - 1000 mm X L (or in coil form)
Length: Fixed length or random length or based on the customer's special requirement.
Chemical Composition and standard
|
X15CrNiSi20-12 1.4828
|
AISI 309 UNS S30900 |
BS 309S24 | JIS SUH309 |
|
EN 10296-2-2005 |
ASTM A 959-2004 | BS 1449-2-1983 | JIS G 4312-2019 |
|
Mo(%): - N(%): ≤0.11
|
C(％): ≤0.2 Mo(%): - N(%): - |
C(％): ≤0.15 Mo(%): - N(%): - |
C(％): ≤0.2 Mo(%): - N(%): - |
X15CrNiSi20-12/1.4828 Mechanical Properties (+P)
Tensile Strength, σb/MPa: ≥550
Yield Strength, σ0.2/MPa: ≥230
Elongation, δ(％): ≥30
Applications
X15CRNISI20-12 W-NR 1.4828 is used to produce special furnace and conveyor components operating at high temperature, such as hooks, porcelain baskets, chimneys and special items operating in dry environment.
