1.4125 DIN X105CrMo17 Stainless Steel Flat Bar UNS S44004 AISI 440C Plates
1.4125 DIN X105CrMo17 Stainless Steel Flat Bar UNS S44004 AISI 440C Plates
Product Information
Stainless steel 440C is a high carbon chromium stainless steel. After hardening, it has good corrosion resistance. It exhibits strong wear resistance and abrasion resistance. It is magnetic under all conditions and produces the highest hardness of hardenable stainless steel.
Size Range
Round bar / Wire rod (Diameter):5.0 mm to 500 mm
Square bar / Flat bar: 3.0 mm to 500 mm
Forging piece: Stepped shafts with flanks / discs /tubes /slugs /donuts /cubes /other different shapes based on OEM.
Heavy/middle plate via hot rolled: T3 - 1000 mm X W10 - 1000 mm X L800-12000 mm
Sheet steel via cold rolled: T1.0 - 10 mm X W5 - 1000 mm X L100 - 1000 mm
Steel strip via cold rolled: T0.5 - 10 mm X W10 - 1000 mm X L (or in coil form)
Length: Fixed length or random length or based on the customer's special requirement.
Chemical Composition and standard
|
X105CrMo 17/1.4125 |
AISI 440C/UNS S44004 | Z100CD17 | SUS 440C |
| DIN EN 10088-3-2014 | ASTM A 959-2004 | NF A 35-565-1994 | JIS G 4308-2013 |
|
C(％): 0.95~1.20 Mo(%): 0.40~0.80
|
C(％): 0.95~1.20 Mo(%): ≤0.75
|
C(％): 0.95~1.20 Mo(%): 0.40~0.80
|
C(％): 0.95~1.20 Mo(%): ≤0.75
|
Mechanical Properties (annealed)
Hardness after annealed/HBW: ≤285
Applications
440C Common terms for producing rolling bearings, valve seats, high-quality blades, surgical instruments, and chisels.
