X2CrTiNb18 W-Nr 1.4509 Stainless True Bar UNS S43940 Plates
X2CrTiNb18 W-Nr 1.4509 Stainless True Bar UNS S43940 Plates
Product Information
1.4509 is a stainless steel material, also known as AISI 441 or EN 1.4509. It is a low-carbon duplex stainless steel with high corrosion resistance and wear resistance. The chemical composition of 1.4509 material includes chromium, molybdenum, copper, and titanium, with a high chromium content that can give it good corrosion resistance.
Size Range
Round bar / Wire rod (Diameter):1.0 mm to 1200 mm
Square bar / Flat bar: 5.0 mm to 1000 mm
Forging piece: Stepped shafts with flanks / discs /tubes /slugs /donuts /cubes /other different shapes based on OEM.
Heavy/middle plate via hot rolled: T5.0 - 1500 mm X W5 - 1000 mm X L100-1000 mm
Sheet steel via cold rolled: T1.0 - 10 mm X W1 - 1000 mm X L100 - 800 mm
Steel strip via cold rolled: T2.0 - 10 mm X W1.0 - 1000 mm X L (or in coil form)
Length: Fixed length or random length or based on the customer's special requirement.
Chemical Composition and standard
|
X2CrTiNb 18/1.4509 |
UNS S43940 |
SUS 430LX |
|
DIN EN 10088-1-2005 ISO 4995-2005 NF EN 10088-1-2005 BS EN 10088-1-2005 |
ASTM A 959-2004 | JIS G 4304-2005 |
|
C(％): ≤0.03 Cr(％): 17.5~18.5 Ti(％): 0.10~0.60 Nb(%): 3xC+0.30~1.00
|
C(％): ≤0.03 Cr(％): 175~18.5 Ti(％): 0.10~0.60 Nb(%): ≥0.30+3xC
|
C(％): ≤0.03 Cr(％): 16.0~19.0 Ti(％): 0.10~1.00 |
Mechanical Properties
Tensile strength,Rm/MPa: 430~630
Yield strength,Rp/MPa: ≥230
Elongation, A/%: ≥30
Reduction of area, ψ/%: -
Hardness HRC: -
Applications
1.4509 stainless steel is commonly used in fields such as automotive exhaust systems, kitchenware, chemical processing equipment, and architectural decoration. Its characteristics include stability at high temperatures, excellent corrosion resistance, and low magnetic permeability. In addition, the 1.4509 material is also easy to process and weld, making it widely used in the manufacturing industry.
