ASTM 405 X6Cr13 Stainless Steel Flat Bar UNS S40500 1.4000 Z6CA13
ASTM 405 Stainless Steel Flat Bar UNS S40500 X6Cr13 Flat Bar 1.4000 Z6CA13 Bar
Description
Our company provides ASTM 405 Stainless Steel Flat Bar UNS S40500 milled X6Cr13/1.4000 Ground bar ASTM A959-2004.
All of ASTM 405 Stainless Steel Flat Bar UNS S40500 milled X6Cr13 Ground bar X6Cr13,SUS405,STS405,X04Cr13,X6Cr13/1.4000,Z6CA13,403S17ASTM A959-2004 conform to Military standard, nuclear power. 100% Ultrasonic test ASTM E2375 /SAE AMS 2154 /SEP 1923 /GB/T 4162 /EN 10228-3.
- Material:Metal,Stainless Steel Flat Bar,ASTM 405,UNS S40500,X6Cr13,1.4000,X6Cr13,SUS 405,STS 405,X04Cr13,X6Cr13/1.4000,Z6CA13,403S17.
- Executive Technical Standards: GB / ISO / DIN / NF / BV / BS / JIS / JASO / NDS / ASTM / SAE / UNS / AISI etc.
- Metal Type:Martensitic stainless steel series.
- Shape: ASTM 405,UNS S40500,X6Cr13,1.4000,X6Cr13,SUS 405,STS 405,X04Cr13,X6Cr13/1.4000,Z6CA13,403S17, Stainless Steel Flat Bar
- Square bar / Flat bar: 3mm to 800mm
- Length: Fixed length or random length or based on the customer's special requirement.
- Surface:Black,Bright or According To Customer Demand.
- 405,X04Cr13,X6Cr13/1.4000,Z6CA13,403S17, Stainless Steel Flat Bar.
- ASTM 405 Stainless Steel Flat Bar UNS S40500 milled X6Cr13 Ground bar ASTM A959-2004 Heat treatment condition: annealed, solution treated, quenched and tempered etc.
Packing details:
Products are well packed and clear labeled according to the regulations and customer's requests.
Intact packages are able to avoid any damage which might otherwise be caused during storage or transportation.
Products Details
ASTM 405 Stainless Steel Flat Bar UNS S40500 milled X6Cr13 Ground bar ASTM A959-2004
| Chemical Composition (weight%): | Mechanical Properties Under Final Heat Treatment: |
| C (％): ≤ 0.08 Si (％): ≤ 1.00 Mn (％): ≤ 1.00 P (％)≤: 0.040 S (％)≤: 0.030 Cr (％): 11.0 - 14.50 Ni (％): ≤ 0.50 Mo (％): - Al (％): 0.10 - 0.30 |
Condition: annealing Tensile strength, σb/MPa: 415 Yield strength, σ0.2/MPa: 170 Elongation, δ(％): 20.0 Reduction of area, ф(％): - Hardness | HBW: 179 Hardness | HRB: 88 Cold bending property: N |
Applications:
Chemical equipment
Mechanical parts used in the condition of corrosion resistance
Bolt and nut
Pressure vessel
| Technical Standard | Equivalent Grade |
| ISO/TS 15510(2003) | X6Cr13 |
| JIS G4303(2005) | SUS 405 |
| KS D3706(2006) | STS 405 |
| IS 6527(2001) |
X04Cr13 |
| DIN EN 10088-1(2005) | X6Cr13/1.4000 |
| NF EN10088-2(2005) | X6Cr13 |
| NF A35-573(1984) | Z6CA13 |
| BS 970-1(1996) | 403S17 |
| ASTM A959(2004) | 405/S40500 |
FAQ
Q: How do you control the quality?
A: We have professional inspectors to analyze the chemical composition of raw materials and test the finished products in strict accordance with the standards stipulated in the contract. In this process, the inner and outer surfaces, the appearance of both ends, bending, set length, outer diameter and Wall thickness will be checked one by one. You can rest assured that all products you receive from us are reliable.
Q: Do you accept customization?
A: Yes. If you have special requirements for products or packaging, we can make them for you.
Q: Can you accept trial orders?
A: Our MOQ is usually 1 ton. However, if you want to place an order as the start of our cooperation, we can accept smaller quantities at the first time. Of course, after the start, we will have further and longer cooperation.
Q: How do I get samples?
A: Free samples are available for your inspection and testing, DHL/FedEx/UPS accounts can be used for sampling, and the courier fee is borne by you.
