ASTM 416 Turbine Blade Steel AMS 5610 CM4265 Round Bar S41600 X12CrS13 1.4005 Flat Bar
ASTM 416 Turbine Blade Steel AMS 5610 CM4265 Round Bar S41600X12CrS13 1.4005 Flat Bar
Description
Our company provides ASTM 416 Turbine Blade Steel AMS 5610 CM4265 Round Bar UNS S41600 Flat Bar X12CrS13 1.4005 Bar ASTM A959-2004.All of ASTM 416 Turbine Blade Steel AMS 5610 CM4265 Round Bar UNS S41600 Flat Bar X12CrS13 1.4005 Bar ASTM A959-2004 conform to Military standard, nuclear power. 100% Ultrasonic test ASTM E2375 /SAE AMS 2154 /SEP 1923 /GB/T 4162 /EN 10228-3.
- Shape:Turbine Blade Steel.
- Round bar / Wire rod (Diameter): 5.5mm to 800mm
- Square bar / Flat bar: 3mm to 800mm
- Length: Fixed length or random length or based on the customer's special requirement.
Products Details
ASTM 416 Turbine Blade Steel AMS 5610 CM4265 Round Bar UNS S41600 Flat Bar X12CrS13 1.4005 Bar ASTM A959-2004
| Chemical Composition (weight%): | Mechanical Properties Under Final Heat Treatment: |
| C (％): ≤ 0.15 Si (％): ≤ 1.00 Mn (％): ≤ 1.25 P (％)≤: 0.060 S (％)≤: ≥ 0.15 Cr (％): 12.0 ~ 14.0 Ni (％): - Mo (％): - |
Condition: annealing Tensile strength, σb/MPa: 485 Yield strength, σ0.2/MPa: 275 Elongation, δ(％): 20 Reduction of area, ф(％): 45 Hardness | HRB: - Form: wire Condition: annealing σb/MPa: 585~860 σ0.2/MPa: - δ(％): - ф(％): - Hardness | HRB: - |
Applications:
Bolt and nut
Pressure vessel
Chemical equipment
Mechanical parts used in the condition of corrosion resistance
| Technical Standard | Equivalent Grade |
| ISO 16143-3(2005) | X12CrS13 |
| JIS G4303(2005) | SUS 416 |
| KS D3706(2006) | STS 416 |
| IS 1570-7(2004) | 12Cr13H |
| DIN EN 10088-1(2005) |
X12CrS13/1.4005 |
| NF EN 10088-2(2005) | X12CrS13 |
| NF A35-576(1984) | Z12CF13 |
| BS 970-1(1996) | 416S12 |
| ASTM A959(2004) | 416/S41600 |
ASTM 416 Turbine Blade Steel AMS 5610 CM4265 Round Bar UNS S41600 Flat Bar X12CrS13 1.4005 Bar
FAQ
Q: How do you control the quality?
A: We have professional inspectors to analyze the chemical composition of raw materials and test the finished products in strict accordance with the standards stipulated in the contract. In this process, the inner and outer surfaces, the appearance of both ends, bending, set length, outer diameter and Wall thickness will be checked one by one. You can rest assured that all products you receive from us are reliable.
Q: Do you accept customization?
A: Yes. If you have special requirements for products or packaging, we can make them for you.
Q: Can you accept trial orders?
A: Our MOQ is usually 1 ton. However, if you want to place an order as the start of our cooperation, we can accept smaller quantities at the first time. Of course, after the start, we will have further and longer cooperation.
Q: How do I get samples?
A: Free samples are available for your inspection and testing, DHL/FedEx/UPS accounts can be used for sampling, and the courier fee is borne by you.
