AM-350 Turbine Blade Steel S35000 16Cr-4Ni-3Mo-N Bar A693 Gr.633 ASTM 633 AMS 5548 Round Bar
AM-350 Turbine Blade Steel S35000 16Cr-4Ni-3Mo-N Bar A693 Gr.633 ASTM 633 AMS 5548 Round Bar
Description
Our company provides AM-350 A693 Gr.633 Turbine Blade Steel ASTM 633 AMS 5548 Round Bar UNS S35000 16Cr-4Ni-3Mo-N Precipitation hardening type Bar.
All of AM-350 A693 Gr.633 Turbine Blade Steel ASTM 633 AMS 5548 Round Bar UNS S35000 16Cr-4Ni-3Mo-N Precipitation hardening type Bar conform to Military standard, nuclear power. 100% Ultrasonic test ASTM E2375 /SAE AMS 2154 /SEP 1923 /GB/T 4162 /EN 10228-3.
- Material:Metal,Turbine Blade Steel,AM-350,A693 Gr.633,AMS 5548,ASTM 633,UNS S35000,16Cr-4Ni-3Mo-N.
- Shape:Turbine Blade Steel.
- Round bar / Wire rod (Diameter): 5.5mm to 800mm
- Square bar / Flat bar: 3mm to 800mm
Products Details
AM-350 A693 Gr.633 Turbine Blade Steel ASTM 633 AMS 5548 Round Bar UNS S35000 16Cr-4Ni-3Mo-N Precipitation hardening type Bar
Austenitic high-tensile superalloy & Precipitation hardening steel
The alloy is usually produced by AOD / VOD /VIM followed by electroslag refining (ESR) / VAR if necessary for special purpose.
| Chemical Composition (weight%): | Mechanical Properties Under Final Heat Treatment: |
| C (％): 0.10 ~ 0.15 Si (％): ≤ 0.50 Mn (％): 0.50 ~ 1.25 P (％) ≤: 0.040 S (％) ≤: 0.030 Cr (％): 15.0 ~ 16.0 Ni (％): 4.00 ~ 5.00 Mo (％): 2.50 ~ 3.20 Nb + Ta (%): 0.15 ~ 0.50 N (%): - |
Tensile strength, σb/≥ MPa: 1170 Yield strength, σ0.2/≥ MPa: 1070 Elonghation, δ ≥(％): 12.0 Reduction of area, ф ≥ (％): 25.0 Hardness | HB: HRC37 |
Applications:
Superalloy is widely used to produce the high temperature components for gas turbine in the field of aviation, naval vessels and industry, such as turbine blade, guide blade, turbine disc, high pressure compressor disc, combustor, and also production of energy conversion devices, such as aerospace craft, rocket motor, nuclear reactor, petrochemical equipments, coaly transforming and so on.
Equivalent Grade:
AM-350
A693 Gr.633
ASTM 633
AMS 5548
UNS S35000
16Cr-4Ni-3Mo-N
AM-350 A693 Gr.633 Turbine Blade Steel ASTM 633 AMS 5548 Round Bar UNS S35000 16Cr-4Ni-3Mo-N Precipitation hardening type Bar
