DIN X20Cr13 1.4021 Turbine Blade Steel DIN X20Cr13 Round Bar DIN 1.4021 Flat Bar
DIN X20Cr13 1.4021 Turbine Blade Steel DIN X20Cr13 Round Bar DIN 1.4021 Flat Bar
Description
Our company provides DIN X20Cr13 1.4021 Hot rolled Bright Turbine Blade Steel DIN X20Cr13 Annealed Round Bar DIN 1.4021 Cold working Bright Flat Bar.
All of DIN X20Cr13 1.4021 Hot rolled Bright Turbine Blade Steel DIN X20Cr13 Annealed Round Bar DIN 1.4021 Cold working Bright Flat Bar. conform to Military standard, nuclear power. 100% Ultrasonic test ASTM E2375 /SAE AMS 2154 /SEP 1923 /GB/T 4162 /EN 10228-3.
- Material:Metal,Turbine Blade Steel,DIN X20Cr13 1.4021 Hot rolled Bright Turbine Blade Steel DIN X20Cr13 Annealed Round Bar DIN 1.4021 Cold working Bright Flat Bar.
- Round bar / Wire rod (Diameter): 5.5mm to 800mm
- Square bar / Flat bar: 3mm to 800mm
- DIN X20Cr13 1.4021 Hot rolled Bright Turbine Blade Steel DIN X20Cr13 Annealed Round Bar DIN 1.4021 Cold working Bright Flat Bar.Forging piece: stepped shafts with flanks / discs /tubes /slugs /donuts /cubes /other different shapes based on OEM.
Products Details
DIN X20Cr13 1.4021 Hot rolled Bright Turbine Blade Steel DIN X20Cr13 Annealed Round Bar DIN 1.4021 Cold working Bright Flat Bar.
| Chemical Composition (weight%): | |||||||
|
C (％): 0.16 ~ 0.25 |
Si(％): ≤1.00 |
Mn(％): ≤1.50 |
P(％)≤: 0.040 |
S(％)≤: 0.030 |
Cr(％): 12.0～14.0 |
Ni(％): - |
Mo(％): - |
| Mechanical Properties Under Final Heat Treatment: | |||||
| Condition: annealing | |||||
| σb/MPa: 690 | σ0.2/MPa: - | δ(％): 15 | ф(％): - | Hardness | HRB: ≤96 | |
| Form: bar | |||||
|
Condition: Tempering (620℃) |
σb/MPa: 1720 |
σ0.2/MPa: 148 |
δ(％): 8 |
ф(％): 25 |
Hardness | HRB: ≤52HRC |
Applications:
Chemical equipment
Mechanical parts used in the condition of corrosion resistance
DIN X20Cr13 1.4021 Hot rolled Bright Turbine Blade Steel DIN X20Cr13 Annealed Round Bar DIN 1.4021 Cold working Bright Flat Bar.
Bolt and nut
Pressure vessel
Equivalent Grade:
DIN X20Cr13 DIN EN 10088-1(2005)
1.4021
DIN X20Cr13 1.4021 Hot rolled Bright Turbine Blade Steel DIN X20Cr13 Annealed Round Bar DIN 1.4021 Cold working Bright Flat Bar.
FAQ
Q: How do you control the quality?
A: We have professional inspectors to analyze the chemical composition of raw materials and test the finished products in strict accordance with the standards stipulated in the contract. In this process, the inner and outer surfaces, the appearance of both ends, bending, set length, outer diameter and Wall thickness will be checked one by one. You can rest assured that all products you receive from us are reliable.
Q: Do you accept customization?
A: Yes. If you have special requirements for products or packaging, we can make them for you.
Q: Can you accept trial orders?
A: Our MOQ is usually 1 ton. However, if you want to place an order as the start of our cooperation, we can accept smaller quantities at the first time. Of course, after the start, we will have further and longer cooperation.
Q: How do I get samples?
A: Free samples are available for your inspection and testing, DHL/FedEx/UPS accounts can be used for sampling, and the courier fee is borne by you.
