UNS S42200 Turbine Blade Steel
ASTM 422 UNS S42200 Turbine Blade Steel ASTM 422 Round Bar UNS S42200 Flat Bar
Description
Our company provides AISI 422 UNS S42200 Rrough Turned Turbine Blade Steel ASTM 422 Machined Round Bar UNS S42200 Shot Blasted Flat Bar.
All of AISI 422 UNS S42200 Rrough Turned Turbine Blade Steel ASTM 422 Machined Round Bar UNS S42200 Shot Blasted Flat Bar conform to Military standard, nuclear power. 100% Ultrasonic test ASTM E2375 /SAE AMS 2154 /SEP 1923 /GB/T 4162 /EN 10228-3.
- Material:Metal,AISI 422 UNS S42200 Rrough Turned Turbine Blade Steel ASTM 422 Machined Round Bar UNS S42200 Shot Blasted Flat Bar.
- Round bar / Wire rod (Diameter): 5.5mm to 800mm
- Square bar / Flat bar: 3mm to 800mm ASTM 422 UNS S42200 Rrough Turned Turbine Blade Steel ASTM 422 Machined Round Bar UNS S42200 Shot Blasted Flat Bar
Products Details
AISI 422 UNS S42200 Rrough Turned Turbine Blade Steel ASTM 422 Machined Round Bar UNS S42200 Shot Blasted Flat Bar.
| Chemical Composition (weight%): | C (％): 0.20 ~ 0.25 |
| Si (％): ≤ 0.50 | |
| Mn (％): 0.50 ~ 1.00 | |
| P (％)≤: 0.025 | |
| S (％)≤: 0.020 | |
| Cr (％): 11.0 ~ 12.5 | |
| Ni (％): 0.50 ~ 1.00 | |
| Mo (％): 0.90 ~ 1.25 | |
| V (％): 0.20 ~ 0.30 | |
| W (%): 0.90 ~ 1.25 | |
| Mechanical Properties Under Final Heat Treatment: |
Form: bar,forge piece |
| Condition: Tempering (620℃) | |
| Tensile strength, σb/MPa: 965 | |
| Yield strength, σ0.2/MPa: 760 | |
| Elongation, δ(％): 13.0 | |
| Reduction of area, ф(％): 30 | |
| Hardness | HRC: 30 ~ 36 | |
| Form: bar,forge piece | |
| Condition: Tempering (675℃) | |
| Tensile strength, σb/MPa: 825 | |
| Yield strength, σ0.2/MPa: 585 | |
| Elongation, δ (％): 15.0 | |
| Reduction of area, ф (％): 35 | |
| Hardness | HRB: ≤ 30 HRC |
Applications:
The high-temperature and high-strength steel,Chemical equipment,Mechanical parts used in the condition of corrosion resistance,Bolt and nut,Pressure vessel.
Equivalent Grade:
AISI 422 ASTM A959(2004)
UNS S42200
FAQ
Q: How do you control the quality?
A: We have professional inspectors to analyze the chemical composition of AISI 422 UNS S42200 Turbine Blade Steel ASTM 422 Round Bar UNS S42200 Flat Bar and test the finished products in strict accordance with the standards stipulated in the contract. In this process, the inner and outer surfaces, the appearance of both ends, bending, set length, outer diameter and Wall thickness will be checked one by one. You can rest assured that all products you receive from us are reliable.
Q: Do you accept customization?
A: Yes. If you have special requirements for products or packaging, we can make them for you.
Q: Can you accept trial orders?
A: Our MOQ is usually 1 ton. However, if you want to place an order as the start of our cooperation, we can accept smaller quantities at the first time. Of course, after the start, we will have further and longer cooperation.
Q: How do I get samples?
A: Free samples are available for your inspection and testing, DHL/FedEx/UPS accounts can be used for sampling, and the courier fee is borne by you.
