DIN X20CrMoW12-1 1.4935 Turbine Blade Steel X20CrMoW12-1 Round Bar 1.4935 Flat Bar
DIN X20CrMoW12-1 1.4935 Turbine Blade Steel X20CrMoW12-1 Round Bar 1.4935 Flat Bar
Description
Our company provides DIN X20CrMoW12-1 1.4935 Peeled Turbine Blade Steel X20CrMoW12-1 Rrough Turned Round Bar 1.4935 Q+T / A+T Flat Bar.
All of ASTM 405 Turbine Blade Steel AISI 405 Round Bar UNS S40500 Flat Bar X6Cr13 1.4000 DE12-0621 Bar ASTM A959-2004 conform to Military standard, nuclear power. 100% Ultrasonic test ASTM E2375 /SAE AMS 2154 /SEP 1923 /GB/T 4162 /EN 10228-3.
- Material:Metal,DIN X20CrMoW12-1 1.4935 Peeled Turbine Blade Steel X20CrMoW12-1 Rrough Turned Round Bar 1.4935 Q+T / A+T Flat Bar.
- Shape:Turbine Blade Steel.
- Round bar / Wire rod (Diameter): 5.5mm to 800mm Square bar / Flat bar: 3mm to 800mm
Products Details
DIN X20CrMoW12-1 1.4935 Peeled Turbine Blade Steel X20CrMoW12-1 Rrough Turned Round Bar 1.4935 Q+T / A+T Flat Bar.
Heat resistant steel is generally smelt in electric arc furnace (EAF) or induction furnace (BEF). For higher quality, it should be smelt via technology of vacuum refining and external refining.
| Chemical Composition (weight%): | |||||||||
|
C (％): 0.20 ~ 0.25 |
Si (％): ≤ 0.50 |
Mn (％): 0.50 ~ 1.00 |
P (％)≤: 0.025 |
S (％)≤: 0.020 |
Cr (％): 11.0 ~ 12.5 |
Ni (％): 0.50 ~ 1.00 |
Mo (％): 0.90 ~ 1.25 |
V (％): 0.20 ~ 0.30 |
W (%): 0.90 ~ 1.25 |
| Mechanical Properties Under Final Heat Treatment: | ||||
| Form: bar,forge piece Condition: Tempering (620℃) | ||||
| Tensile strength, σb/MPa: 965 | Yield strength, σ0.2/MPa: 760 | Elongation, δ(％): 13.0 | Reduction of area, ф(％): 30 | Hardness | HRC: 30 ~ 36 |
| Form: bar,forge piece Condition: Tempering (675℃) | ||||
| Tensile strength, σb/MPa: 825 | Yield strength, σ0.2/MPa: 585 | Elongation, δ (％): 15.0 | Reduction of area, ф (％): 35 | Hardness | HRB: ≤ 30 HRC |
Applications:
DIN X20CrMoW12-1 1.4935 Peeled Turbine Blade Steel X20CrMoW12-1 Rrough Turned Round Bar 1.4935 Q+T / A+T Flat Bar.
Equivalent Grade:
DIN X20CrMoW12-1 DIN EN 10088-1(2005)
1.4935
FAQ
Q: How do you control the quality?
A: We have professional inspectors to analyze the chemical composition of raw materials and test the finished products in strict accordance with the standards stipulated in the contract. In this process, the inner and outer surfaces, the appearance of both ends, bending, set length, outer diameter and Wall thickness will be checked one by one. You can rest assured that all products you receive from us are reliable.
Q: Do you accept customization?
A: Yes. If you have special requirements for products or packaging, we can make them for you.
Q: Can you accept trial orders?
A: Our MOQ is usually 1 ton. However, if you want to place an order as the start of our cooperation, we can accept smaller quantities at the first time. Of course, after the start, we will have further and longer cooperation.
Q: How do I get samples?
A: Free samples are available for your inspection and testing, DHL/FedEx/UPS accounts can be used for sampling, and the courier fee is borne by you.
