1.4597 X8CrMnCuNB17-8-3 Flat Metal Panels Stainless Flat Bar
DIN EN X8CrMnCuNB17-8-3 1.4597 Stainless Steel Flat Bar X8CrMnCuNB17-8-3 Flat Bar 1.4597 Bar
Description
Our company provides DIN EN X8CrMnCuNB17-8-3 Forged Bar 1.4597 Stainless Steel Flat Bar X8CrMnCuNB17-8-3 Hot Rolled Flat Bar 1.4597 ESR refined Bar.
All of DIN EN X8CrMnCuNB17-8-3 Forged Bar 1.4597 Stainless Steel Flat Bar X8CrMnCuNB17-8-3 Hot Rolled Flat Bar 1.4597 ESR refined Bar conform to Military standard, nuclear power. 100% Ultrasonic test ASTM E2375 /SEP 1923 /GB/T 4162 /SAE AMS 2154 /EN 10228-3.
- Material:Metal,Stainless Steel Flat Bar,DIN EN X8CrMnCuNB17-8-3 1.4597.
- Shape:Stainless Steel Flat Bar.
- Square bar / Flat bar: 3mm to 800mm
Products Details
DIN EN X8CrMnCuNB17-8-3 Forged Bar 1.4597 Stainless Steel Flat Bar X8CrMnCuNB17-8-3 Hot Rolled Flat Bar 1.4597 ESR refined Bar.
| Chemical Composition (weight%): | C (％): ≤ 0.10 |
| Si (％): ≤ 2.00 | |
| Mn(％): 6.50 ~ 8.50 | |
| P(％): ≤ 0.040 | |
| S (％): ≤ 0.030 | |
| Cr (％): 16.0 ~ 18.0 | |
| Mo (％): ≤ 1.00 | |
| Ni (％): ≤ 2.00 | |
| Cu (%): 2.00 ~ 3.50 | |
| B (%): 0.0005 ~ 0.0050 | |
| N (％): 0.15 ~ 0.30 | |
| Mechanical Properties Under Final Heat Treatment: |
Heat treatment: solution annealed |
| Product form: cold rolled | |
| Thickness: ≤8/ (Hot rolled 13.5) | |
| Tensile strength, σb/MPa: 580 ~ 780 | |
| Yield strength, σ0.2≥/MPa: 300 | |
| Elongation, δ5≥(％): 25.0 | |
| Reduction of area, ψ≥(％): - | |
| Impact strength, Akv≥/J: - | |
| hardness HBW: - |
Applications:
DIN EN X8CrMnCuNB17-8-3 Forged Bar 1.4597 Stainless Steel Flat Bar X8CrMnCuNB17-8-3 Hot Rolled Flat Bar 1.4597 ESR refined Bar.
Bolt and nut,Chemical equipment,Mechanical parts used in the condition of corrosion resistance,Pressure vessel.
Equivalent Grade
DIN EN X8CrMnCuNB17-8-3 DIN EN 10088-1 2014
1.4597
DIN EN X8CrMnCuNB17-8-3 Forged Bar 1.4597 Stainless Steel Flat Bar X8CrMnCuNB17-8-3 Hot Rolled Flat Bar 1.4597 ESR refined Bar.
FAQ
Q: How do you control the quality?
A: We have professional inspectors to analyze the chemical composition of DIN EN X8CrMnCuNB17-8-3 Forged Bar 1.4597 Stainless Steel Flat Bar X8CrMnCuNB17-8-3 Hot Rolled Flat Bar 1.4597 ESR refined Bar and test the finished products in strict accordance with the standards stipulated in the contract. In this process, the inner and outer surfaces, the appearance of both ends etc and Wall thickness will be checked one by one.
Q: Do you accept customization?
A: Yes. If you have special requirements for products or packaging, we can make them for you.
Q: Can you accept trial orders?
A: Our MOQ is usually 1 ton. However, if you want to place an order as the start of our cooperation, we can accept smaller quantities at the first time. Of course, after the start, we will have further and longer cooperation.
Q: How do I get samples?
A: Free samples are available for your inspection and testing, DHL/FedEx/UPS accounts can be used for sampling, and the courier fee is borne by you.
